Dogwatch Kudos

I want to express my appreciation for a tip I got in The Dogwatch today (“LED Light and RFI Feedback,” November 2019). I had seen the earlier RFI/LED article and had made a mental note to check if my LED tricolor interfered with my masthead VHF. Reading the readers’ feedback, a note from Brent Putnam triggered a light bulb in my head. My cheap and infrequently used AM/FM stereo had developed a bad static problem. I had pulled it, checked the antenna, power and speaker leads, and gave it a gentle whack. No better. My troubleshooting skills exhausted, I resigned myself to replacing it someday. After reading Mr Putnam’s mention of USB chargers giving RF interference, I unplugged the Chinese panel mount unit I had installed nearby. Problem fixed. Thanks to Good Old Boat and your readers.

–John Churchill, Nurdle, 1979 Bristol 35.5 CB

Dog Phobias?

Reading about ancraophobia and anemophobia in the November issue of The Dogwatch makes me wonder whether these anxieties can also apply to dogs. It’s ironic, but the little starving puppy we found on an uninhabited island in the Kuna Yala, and who sailed more than 8,000 miles with us for two years before we returned to land, is now clearly experiencing this problem. Thunderstorms don’t alarm her, but when there’s a big wind blowing, she’s a mess. It’s especially bad if the breeze randomly slams a door shut in the house, so if a big wind is forecast, I go around propping doors with workboots to preclude this source of terror. I don’t want to medicate her with the typical drugs that would make her all dopey. I’m considering CBD oil for dogs as a possible alternative. It makes me sad to see her so scared, and especially to think that she grew up on a sailboat in big water. But, maybe we all gain a few weird fears as we grow older. Does anybody else have a dog who suffers ancraophobia?

–Wendy Mitman Clarke, Good Old Boat senior editor

Some Advice for Capt. Rob

Regarding the letter from Capt. Rob in the November issue of The Dogwatch, about the starting problems he is having: I have a Yanmar SB12, which is also a small, single-cylinder diesel. When you turn your motor over by hand with the compression release engaged, each time the piston passes through top dead center, you should be able to hear the injector make a distinct “squoit” noise as it squirts a drop of fuel into the combustion chamber. If you do not hear this noise, the motor will never start, and you probably have an issue with air in the high-pressure side of the fuel line. It is also possible that the injector is bad, but this is much less likely and most certainly not the issue if the engine was running okay and now it won’t start. Learn to recognize this sound and you’ll always be able to tell if the motor is going to start or not.

–Homer Shannon, Cinderella, Bristol 29.9

I saw the letter in the November issue of The Dogwatch, about Capt. Rob’s diesel engine problem. I had a real interesting experience with the fuel system on my Pacific Seacraft 31. I had the marina change out my fuel lines and service the primary fuel filter (Racor 500FG). Afterward, I started experiencing air leaks in the suction side (before the electric and engine-driven fuel pumps). Soon after I’d begin to see air bubbles through the Racor filter inspection bowl glass, the engine would lug and die.

The first thing I found was the O-ring inside the filter cap had not been seated properly and was damaged. I replaced this O-ring and the engine ran for 45 minutes without a problem.

But several weeks later, it started lugging and dying again. I got pretty good at quickly bleeding the air and limping back to the marina! I started thinking I had something wrong at the fuel tank pickup, so I started removing hoses from hose barbs and inspecting the fittings.

I found that all the fuel hose was 5/16-inch and the barbed fittings were ¼-inch. Seems either the marina did not have ¼-inch fuel hose and substituted 5/16, or the previous owner/mechanic had changed to 5/16 at some time over the boat’s 29-year life. Changing to ¼-inch hose seems to have solved the problem.

By the way, in the fall of 2018 I attended a diesel teardown class in Chicago; followed by a diesel rebuild session in the spring of 2019. Best thing I have ever done for myself in regards to understanding the iron beast.

–Daryl Clark

The Most Unusual Things: Feedback

Last month we said we’d share the most unusual man-made thing we’d seen from a boat, and the most unusual wildlife we’d seen from a boat—not necessarily the coolest thing, but the most unusual, the thing others are least likely to report. And we put it to the readers, wondering what others have seen while sailing. We’re surprised at the low number of responses, but we got some very good ones.

First, as promised, here are the most unusual things we’ve seen, both sightings within weeks of each other. It was early fall 2013 and we were sailing our 1978 Fuji 40 down from Alaska, on our way to Southern California. It was then two years after the tsunami that triggered Japan’s Fukushima Daiichi nuclear disaster and reports of Japanese stuff washing up on Pacific Northwest beaches had been coming in all summer. As we sailed along the desolate coastline of the northern end of British Columbia’s Vancouver Island, we started seeing things in the water, Japanese things. In remote anchorages along that coastline, we found beaches covered in Japanese goods, nearly all plastic. There were lots of oyster floats, and lots of things we couldn’t identify, but most disturbing were the recognizable consumer goods.

On the wildlife front, it was about a week earlier and a bit further north that we saw our first and only sunfish, about 15 miles offshore. They’re the largest bony fish on earth. They’re flat and tail-less and occasionally hang out on the surface like this. They eat jellyfish, which makes sense as that part of the world is teeming with jellyfish.

Because he told the story that we can’t get out of our heads and because it must be the most unusual thing ever, we’ll give Rick Lamb the first word…  –Eds.

***

The most unusual wildlife thing: a squirrel that must have choked while carrying a nut. It was when I was rowing an aluminum boat on an Indiana pond. The squirrel was dead and floating in the water, but the nut had sprouted and the tendrils of roots and leaves were growing from its mouth. The squirrel was turning into a tree, presuming it would wash ashore where the roots could hold.

–Rick Lamb, Carmel, Indiana

Probably about 1980 or ’81, headed to the BVI from Lauderdale, 120′ Feadship. Very calm, gorgeous, mirror sea, and clear blue sky. Making 10 knots, probably about 20 miles off Great Inagua. Something odd off the starboard bow prompted a “let’s go see” course change.

A perfect, complete, probably 8-foot-long sofa with all the proper cushions in place, including arm rest covers, dark brown leather, just drifting along. NOT sinking! Just looked like you could stroll right over, plop down, turn on the TV and grab some popcorn in time for the show!

–John Sims

One of the draws of being a snowbird (who heads south to Florida from Ontario to escape the cold of winter) is being able to see wildlife we don’t see up north in our neck of the woods. Alligators, dolphins, and pelicans, are all good examples—or they all were until a couple years ago. It was a couple years ago, boating in Hamilton Harbour, when I was shocked to see what looked like a single white pelican floating about. This great bird dwarfs the ducks, Canadian geese, and swans which are common in Lake Ontario. I checked in with a friend of mine who happens to be a birder. He assured me I had lost my mind. And then the local paper backed me up. Apparently, pelicans occasionally stop in our waters on their migratory journey. Who knew?

–Lee Brubacher, Hamilton, Ontario

Man-made: once came across a refrigerator floating in the Bay of Fundy, going out with the tide. No idea where it might have come from!

Wildlife: one day late this summer, I found a hummingbird doing the breast stroke a mile or so offshore. After a challenging MOB drill, managed to get it aboard. It was quite a warm day, so hoped it would dry off and warm up but the little guy didn’t make it. He (?) was buried with full honors in my wife’s flower garden.

–Gord Phillips, Lord’s Cove, New Brunswick

I spotted something while sailing a few years ago. I moor and sail my boat at a local lake in Alberta and I do frequent over-nighters on my boat to enjoy the wildlife as well as the sunsets and sunrises. After one such night on my boat, I had breakfast and a leisurely coffee before setting sail for the homeward trip. I was just getting under way when I spotted a white object floating just beneath the surface of the water about 50 meters away. I carry a small fishing net and I am in the habit of scooping up garbage that finds its way into “my” lake.

I changed my heading and went straight for this garbage. As I drew closer I could see that it was actually a dead fish, not an uncommon find on the lake, unfortunately. It looked quite large so I got closer to investigate. Turns out it wasn’t a fish, but two fishes, a smaller one was firmly lodged in the mouth of a larger one! A glaring example of “biting off more than one can chew!” Of course, I had brought a camera with me on that trip, but I’d neglected to charge the battery.

–Mark Stricklin

I hope this qualifies for your a most unusual inanimate object (man-made thing). Without reading further, can you guess what the photo is about?

This is a photo of the bow of a boat I spotted at Havre Polyvalent-Ste-Anne-des-Monts, on the St. Lawrence River off Quebec, Canada. I could not for the life of me see why someone would want a splash guard on the bow of their boat. Upon closer inspection, I realized it was a seat for a pedal-powered windlass! Cool or what?!

–David Takahashi, Chikara-Ni, Alberg 37

Diesel Auxiliary Trouble

I have a ComPac23 Diesel sailboat that I am restoring. I am having trouble getting the 8 HP 1GM10 Yanmar diesel to start. There is plenty of fresh fuel in the tank and I have replaced all the fuel filters and cleaned the injector. The batteries are new and fully charged. The compression test shows 300 PSI. Yet, it just cranks and there is no combustion. I am seeking help. Can you recommend a good Yanmar diesel mechanic I can talk to?

–Capt. Rob, Waleska, Georgia

Hi Rob,

We’re not mechanics, but we’ve lived for years with 3 diesel engines: a Universal 5411 (11hp), a Yanmar 4JH-TE (55hp turbo), and an International 7.3L IDI (in our truck).

Assuming the 300psi compression value is correct for your engine, we can think of only three possible culprits:

• Air in the fuel line
• Poor injection
• Not enough pressure from the high-pressure pump

Here’s what we know about those scenarios:

1. On our Yanmar, we had a problem where it died and wouldn’t restart. We removed the primary (on the engine) spin-on fuel filter and it was half-empty. We filled it, it started, then died 10 minutes later. More air had appeared in this filter cartridge. The fuel tank was full. The air was being sucked in from old fuel lines that had cracks or were too stiff to get a good seal at the fittings they attached to. Replaced lines, problem solved. If you’re sucking air someplace, this will cause a no-start problem. In addition to checking the filter, do your regular bleed procedure and see if you can find air anywhere. In addition, while cranking, you can crack the nuts attaching the metal fuel line to the top of your injector–you should see fuel spitting out. If not, it’s likely a pump problem or an air problem.
2. You wrote that you “cleaned” the injector. Injectors are not DIY, so your problem could very well be a bad injector. But the only way to diagnose this is to send it in to a diesel injector shop. Our advice is to buy a new injector to install and if that solves your problem, have the old injector serviced and keep it as a spare. As you know, diesel will not combust until atomized, and that must happen at about 3,000 psi and if an injector is “clean” it could still have a weakened spring that’s releasing the fuel in a dribble or something.
3. Our understanding is that high-pressure pumps rarely fail, but the one on our truck did (it’s a 1988 with 200K miles). They are expensive and we know nothing about diagnosing them specifically, but I do know that if everything else is good, that’s all that’s left. I would discount this as your problem and focus elsewhere.

The beauty of diesels is their simplicity. If you’re getting clean diesel atomized into a cylinder with good compression, along with clean air, it has no choice but to fire. Your job is to determine which part of the equation isn’t happening. Don’t get discouraged, just cover all the bases and think it through.

Yanmar is funny about geography. Authorized parts dealers can’t sell (even by mail) outside their territory. You should be able to find your authorized parts seller from the Yanmar site. That part seller would probably be happy to answer questions and will know the best mechanics in your area–but hopefully, you can diagnose and fix this one yourself.

If anyone has better information for Rob, let us know and we’ll pass it on.

—Editors

Dogwatch Kudos

I enjoyed another excellent issue of The Dogwatch. I plan to follow up on the YouTube series on the “Great Canal Journeys” that you reviewed; the first few minutes of Episode 1 looks promising!

–David Salter

LED Light and RFI: Feedback

Last month we acknowledged that LED lights are taking over the world and that the incandescent bulb is dead. We made clear that not all LED lights are created equal and that in addition to quality concerns (it varies widely, in our experience) and color considerations (warm or cool temperature light?), the US Coast Guard and others have been warning of the potential for LED lights to interfere with VHF radio reception and transmission. This is especially problematic at the masthead, where VHF antennas and LED anchor or navigation lights may be mounted in proximity. So, we put it to the readers, wondering whether anyone has installed an LED light that caused problems with VHF radio reception?

Because he’s got an illuminating story—sorry—we’ll give Andy LaJambe the first word…  –Eds.

***

Though my experience is not with LED bulbs in a marine application, it does graphically illustrate that there can be a problem. My experience was with the bulbs in my garage door opener.

One day the garage door opener remote failed to close the garage door. I figured the battery was getting low and so would not transmit a strong enough signal from in the driveway where I park the truck. But I was proven wrong because it would open the garage door when I came home.

Through multiple trials that left me more stumped than I was to begin with, I finally figured out that if the lights on the opener were off, the remote would work, and if the lights were on, the remote wouldn’t work. I took the LED bulbs out and the opener worked reliably. Then, I replaced the bulbs, after carefully wrapping foil around the base of the bulbs where the electronics were. This helped a lot, but did not solve the problem.

After a bit of research, I found some FCC-certified bulbs that worked like a charm. They were not inexpensive like the Made-in-China bulbs they replaced, but they have now been installed for 4 or 5 years and have not failed.

It is obvious that not all bulbs are created equal.

I wonder whether the FCC certifies bulbs used in marine (12-volt, non-household) applications?

–Andy LaJambe

We replaced all our incandescent bulbs aboard our Bristol 29.9, Pegu Club, with LED bulbs about four-and-a-half years ago, during a refit. Since that time, we have experienced no issues concerning VHF radio reception. I did read the information from the coast guard a while back and I have yet to hear any first-hand stories of any negative effect on VHF systems from LED bulb interference. For what it’s worth, we purchased our LED bulbs from both Marine Beam and Dr. LED.

–Jeff and Kimberly Boneham

We had this issue in spades with an OGM masthead light we installed right before our last cruise, in 2009. We realized it was interfering when we were on one of our first overnight sails down the coast; we had better reception using a hand-held VHF in the cockpit than we did using our installed radio with the antenna on the mast, right next to that light. When we alerted OGM, they were less than helpful, insisting the source of the problem was our installation, despite us trying everything they recommended. Weems & Plath recently bought OGM and reminded everyone that they offer a lifetime warranty on these lights. They also made clear these lights are “no-interference certified by the US Coast Guard.” We approached Weems & Plath (and the Coast Guard) about our light and Weems & Plath asked us to bring it in for testing. When I dropped it off, Weems & Plath doubted the light would be the source of the problem, but after testing it they confirmed it was causing interference and pledged to fix it. They’ve returned it to us with a Coast Guard-tested LED bulb and we’ll go back aloft and reinstall it later this fall. Fingers crossed!

–Nica Waters, Good Old Boat

I have had interference occur with LED household light bulbs on amateur radio frequencies in VHF 2M band. Turning the lights off solved the problem, and I did not chase it further, but suspect it was RF related. I was told the interference was not audible in my transmission, but it was audible on received audio from other stations.

Rig was an ICOM 706 Mark 2, with 9-element yagi tuned for 2M on a large tower fed with LMR-400 coax feedline.

I have cheap LED lights in my cabin lighting on my Corinthian 19. The fixture used a medium (household) base bulb, and I sourced LED ones online which fit and are 12-volt. These bulbs are extremely annoying due to reception interference with the VHF (weather forecast, etc). I do not know if this is audible on transmit. Of course, the solution is to not listen to the weather forecast while in the berth with the lights on, but rather to turn the lights off (for ambiance) and lay back and listen to the sultry tones of “friendly guy” on Environment Canada WeatherRadio while trying to nod off. As it happens, these bulbs also “sing” if you listen carefully to them.

–Dante McLean, Sam, Alberg 30

I’m Tom Luque, owner of MastGates.com

I have studied LEDs for many years and noticed that low-cost LEDs use a resistor to limit current and thus not generate interference. But this approach wastes power and the quality of light varies with voltage-level change.

The more expensive LED systems use Pulse Width Modulation (PWM) to control the current over a wide range of voltages. PWM is an efficient approach, using the least amount of current to provide a constant level of brightness and color temperature. You will find these circuits under “constant current supplies.” The older constant current circuits use a linear control transistor that waste power like a resistor does, and does not emit frequencies like the more efficient PWM types.

The frequency range emitted by a PWM circuit varies with the battery voltage level. I do not know and have not tested if the frequency range is a problem for other electronics.

I assume that Dr. LED uses PWM because the components I can see being used within the bulb look to be PWM circuitry. Having this type of bulb on the masthead next to the antenna may cause interference.

By the way, even though an LED can produce white light, the light spectrum used by LEDs to make white contains much less of the light spectrum that bugs can see. This is why LED street and parking lights don’t have swarms of bugs around them.

–Tom Luque, owner of MastGates.com, Camas, Washington

It’s not the LED, it’s the power supply. Many electronics require some sort of power supply to convert the available power to what they can use. For example, cars and boats have 12-volt systems, but many electronic devices use 5 volts.

How do I know? I’ve been an FCC-licensed amateur radio operator for over 25 years. We’ve seen the shift from tubes, to transistors, to chips—and the corresponding miniaturization of power supplies. Modern switching power supplies are small and light (no big metal transformer), but they can be noisy. To make things even smaller, many companies skip the parts required to filter and suppress noise. Indeed, some of the most common noisemakers are the USB buttons that fit into a 12-volt lighter socket to power your phone.

If a manufacturer has cut corners, you’ll hear it.

–Brent Putnam

–Preston

Eye Patches for Night Vision?

I believe that the depiction of scurvy, salty, scalawags—buccaneers and privateers all, matey!—wearing eye patches is almost certainly a Hollywood trope, meme, or myth. I think that if a pirate could preserve night vision by covering one eye, wouldn’t that technique have trickled down to fishermen, merchantmen, and various navies? Wouldn’t a selection of stylish eye coverings in a variety of price ranges be found in every chandlery? Sailors on port call do talk about more than booty and rum and…parrots.

However, in defense of the idea that the patch has a night-vision-preserving function, the “MythBusters” cable TV show included this item in a pirate-themed episode. Following is a summary of episode 71. I recommend renting the episode, perhaps from Amazon, it’s quite entertaining!

Pirates wore eyepatches to preserve night vision in one eye. PLAUSIBLE

This myth works under the assumption that the eye covered with the eyepatch is already accustomed to low light conditions, while the other eye must take time to accustom. The MythBusters were sent into a dark room with light-accustomed eyes and were told to complete certain objectives. Their movements were hampered by the darkness and it took them five minutes to finish. When they went into a rearranged but equally dark room with an eye that was covered for thirty minutes, the MythBusters were able to complete the test in a fraction of the time. As a control test, the MythBusters then went back into the same exact room with light-accustomed eyes and ran into the same difficulty as the first test. The myth was deemed plausible because there is no recorded historical precedent for this myth.

Now the real question, not addressed by the MythBusters, is: Are pirates and ninjas truly mortal enemies? Aargh!

–Cory R. Carpenter, C22, Bright Eyes, somewhere just off the coast of Georgia

Helping Bahamians

We’re sad about what happened to the Abacos last month. It’s a tragedy and those wonderful people have a long recovery ahead, a recovery that will extend long after the news reports end.

I’ve done some research and found a charity that is doing good work there. It’s called All Hands and Hearts. They received a 94-percent rating from Charity Navigator, and all All Hands and Hearts donations earmarked for the Bahamas are being matched by Norwegian Cruise Lines. For more info: allhandsandhearts.org

Cover Kudos

The September Good Old Boat cover looks great! Thank you.

–Gino Del Guercio, s/v Andiamo

Carrying a Load

I need to haul out my 1975 29-foot Erickson to clean the bottom. I’ve read that her displacement is between 7,300 pounds and 8,500 pounds. My question is: what size trailer do I need (in terms of its rated load carrying capacity) to haul the boat a short distance uphill to a cleaning area at the yacht club?

–Jim Fish, Ladyfish, Lake Canyon Yacht Club, Canyon Lake, Texas

Hi Jim,

We don’t have a definitive answer, but our guess is that if the path is smooth, you could get away with using a trailer rated to carry much less. Keep in mind that it’s not just trailer ratings, but tire load ratings (from which a trailer rating may be derived?). Regardless, we suspect that any load capacity ratings are going to make allowances for high speeds, the increased loads created by bumps, and longevity. Hopefully a reader or two has better insight or experience.

If anyone has better advice information for Jim, contact him directly at: jfishcz@gvtc.com

—Editors

Steering Cable Thoughts

We know that planes are different than boats, that they operate in different environments. But they both use wire rope cables for controlling a rudder and it seems, anecdotally, that the failure rate for steering cables in boats is much higher than in planes. Is the different environment the reason? Other causes? So we put it to the readers, and we put it to Edson, the maker of sailboat steering systems for many decades.

We’ll give Will Keene, Chairman of Edson International, the first word, and Adam Cove, CEO of Edson International, the second word, as they both have great information to offer…  –Eds.

***

For the past 40+ years, the design and layout of steering systems for sailboats has been my principal occupation. Please consider the following regarding comparing steering systems and steering system failures on boats to those on planes.

• You don’t need a license or training to own and operate a sailboat and there are no regulated inspection protocols in place for sailboats, no FAA regulations.
• Sailboats can be built by anyone, literally, and many sailboat builders built boats in countries with very low labor rates, and accordingly low levels of knowledge of what a sailboat is and the environment in which it operates.
• The American Boat and Yacht Council (ABYC) has standards, good standards, for steering systems, but they are minimums. For example, in addressing the minimum bend radius of ¼-inch 7×19 wire rope, it is permitted to pass over a 4-inch sheave. But designing to minimums is not optimal and many builders do it out of necessity, of one form or another. Sheave size is often dictated by the need to accommodate a fuel tank or berth under the steering pedestal. And until the past decade or so, there was little incentive to follow any rules; CE rules and ABYC standards have changed that, to an extent, in a good way.

Edson recommends changing steering system cables and chain every 7-10 years (just like the common standing rigging recommendation), depending upon use and maintenance. Typically, chain used in steering systems is likely to fail before cable/wire rope and this failure is typically the result of zero maintenance (and when I say zero, I mean zero).

When I hear of a steering chain failure, I usually ask how the boat owner enjoyed their trip to the Caribbean, where the salt in the atmosphere attacks all things stainless. The broken chain always lacks any sign of oil or crevice corrosion protection. When I speak at cruising seminars, I suggest all sailors headed to the Caribbean oil steering chain and cable after every two bottles of rum. I always get some laughs, but my point is serious. Every sailboat I’ve inspected that’s spent a winter in the Caribbean shows signs of rust on all the stainless steel aboard. We see the results of maintenance being neglected.

Edson steering systems employ 305 stainless steel steering wire that is pre-stretched to 60% of breaking strength. We specify 3/16th inch wire on boats up to 38-40 feet. Above 40 feet we specify ¼-inch diameter wire. This wire never breaks simply because the loads exceed the wire strength. Steering cable failure happens as a result of misalignment (a maintenance issue) in which the wire is left to chafe on the edge of a quadrant groove or sheave groove, and then it breaks strand by strand.

Failure is also the product of lack of necessary wire tension (a maintenance issue). Steering cables stretch over time. If you move your steering wheel back and forth and there is play in the system, it’s time to look at cable tension. The rudder should always move when the wheel turns, without slop. Steering system cables should not be taut like they’re in a musical instrument, but they should not droop when the wheel is turned hard against the rudderstops. And tensioning adjustments must be equal; two turns on the tensioning nut on the portside must correspond to two turns on the starboard side tensioning nut. Tensioning just one side will simply move more chain to one side of the sprocket, allowing the “short” side of chain to travel over the sprocket, which will ultimately result in failure as wire does not like to run over the teeth on the sprocket.

Steering cables should be lightly oiled each time they are inspected (2-3 times per season, at a minimum). Apply 30-weight oil to a pad of white tissues and run it over the wire to coat; any meathooks will be flagged by pieces of white tissue and indicate it’s time to change the wire, immediately. And don’t waste time replacing just the one wire, replace the chain and all wire rope at the same time. And don’t stop there. While the patient is on the operating table, inspect the idler plate under the pedestal; if you see rust, replace the plate. Any engine and transmission control cables on the pedestal use steel jacketed cables and these should be replaced at least every 15 years.

We recommend U-bolts/wire clamps as they can be easily installed and they allow you to keep the old wires as spares if they are in good shape. (And remember, when using U-bolts, never saddle a dead horse. The saddle of a U-bolt must be on the working end of the wire.)

Maintenance and attention are key, even for a properly designed/built system. Following are three extreme examples of how successful a well-designed system, properly maintained, can be:

• Pelagic is Skip Novak’s extreme-latitude 50-foot sailing vessel. His (Edson) pedestal steering system is in for replacement after an estimated 500,000+ miles.
• The BT Global Challenge fleet of 60-foot vessels (sailing around the world the “wrong” way) collectively completed over 2,000,000 miles without a steering system incident of failure.
• Mike Plant’s first Vendee Globe sailboat, a 50-foot Roger Martin design, sailed the non-stop around-the-world race four times without replacing the steering system wire.

There is a story behind every failure and every success, and the words “proper design,” “inspection,” “maintenance,” and “neglect” come up in each story, just in different contexts.

I invite everyone to visit edsonmarine.com and look at the Product Support page. There we have Steering Inspection Checklists, Maintenance Guides, and Steering Data Sheets for many different boats. And if you don’t find information for your specific boat, please call as we can perhaps provide you specs or drawings for your boat’s system. Additionally, our EdsonMarine YouTube channel features dozens of videos, many of which cover steering systems.

Outside of work, I’m a guy who loves to buy and fix up old sailboats. After thru-hulls and hull integrity, I always tackle steering systems. I wouldn’t drive my car if I had any concerns about steering, and I apply the same logic to my boats.

If any The Dogwatch (or Good Old Boat) readers have any questions about sailboat steering systems, please call us. When you do, you very well might get me on the line. Edson values good old-fashioned customer service. In fact, if any readers need to reach me during non-business hours, please feel free to call me on my cell 24/7/365 at 508-353-5829. That is my way of saying “Thank You” for a wonderful 40-year career as steward of a 160-year-old company with a wonderful history and great customers.

–Will Keene, Chairman, Edson Intl.

Before I graduated from Michigan’s Naval Architecture and Marine Engineering program, I studied Aerospace Engineering at Embry-Riddle. While aero isn’t my area of expertise, I can count on a ready pool of friendly pilots (commercial and recreational) and aero engineers to offer expertise.

Failures do happen on small aircraft, and they are due to the same cause as most failures on boats: lack of a proper inspection and a disregard for recommended replacement intervals. You could go dig through some FAA reports to see these, or check out any number of forums online, like this one.

I suggest ignoring the cases of the planes/boats that have been flying/sailing for 40 years without an issue. While steering systems can last that long, the odds of failure increase dramatically with time. Replacement intervals are meant to keep the operator safe from what is not feasible to inspect. With steering systems out of sight, they are often neglected and rarely inspected.

Every Edson system failure I have seen could have been prevented by proper installation, inspection, and replacement of equipment, with the exception of catastrophic situations like hard groundings and high-impact collisions. We produce equipment for one of the worst environments on the planet. Corrosion and fatigue are constant adversaries. Inspect systems and respect replacement schedules to win that battle. We also see improper installations. Boats are not regulated to the same degree as aircraft. Despite our specs and recommendations, we see poor installations on a regular basis (from the factory and modifications made down the road by others). Anyone is capable of buying our equipment and installing any way they want, without any inspection required by any governing body.

I love going into design details and speaking about our products. I would be glad to go into more details about specific failure cases, components, connections, and general theory, if anyone wishes to reach out: adam@edsonintl.com.

We are available any time to assist. Our team is here to keep you safe on the water. We are dedicated to creating the best equipment and welcome your feedback. Steering has come a long way in our 160-year history, and we are excited to continue to push it forward with advances in materials and processes.

–Adam Cove, CEO, Edson Intl.

As a pilot for 50 years (I once flew my two-place 65-horsepower 1946 Taylorcraft from Richmond, Virginia, to Tampico, Mexico), I can tell you that airplane cables, as well as most other parts, are built to a very high standard. You cannot just get out and walk if something breaks. I have also been a boater for over 70 years.

–Wm. H. “Bill” Hummel, Wilmington, North Carolina

Airplanes don’t typically live in salt water.

–Joe Klerekoper

I am proactive and check the cables every once in a while when in the bilge (often). I found a meat hook (on one side, around the quadrant) and replaced the cable.

–Dana Mace, Capricious, C&C 27, Marblehead, Massachusetts

Comparing light planes’ steering cables and boats’ steering cables is like comparing apples and oranges. They don’t exist in the same environment, including humidity levels, heat, and salt air exposure.

Having spent 10 years flying helicopters off the backs of frigates, I can tell you that old Navy helos (H-2s, H-3s, H-60s, for instance) didn’t last 40+ years operating in salt fog environments without way more than annual inspections. While at sea, we aircrew had to do a weekly stem-to-stern inspection to find corrosion opportunities, and to turn over every paint nick and corrosion sighting to the metalsmiths for action. Ashore, not so much, just bi-weekly corrosion inspections and freshwater washdowns any time we operated over water.

I’d suggest selecting more corrosion-resistant control cables, along with frequent careful inspections for wear, tear and corrosion, and scheduled replacement after exceeding manufacturers’ or experts’ service life recommendations, all would serve to prevent almost all failures.

Probably preaching to the choir, but hope this helps!

–Dave Lincoln

I have little to add as the cable in my 1976 Ranger 33, which is probably original, still appears ok, but I don’t know how to do a full inspection. The boat has been on freshwater its whole life. But I think comparing boat cables to plane cables is an excellent idea and I agree that the marine failure rate is too high. If the cause is cables that are under-specified, that would be a shame because I would think we could double or triple their diameter with only a increase in cost of less than $100.

–Damon, Stray Cats

Hi Damon, It sounds like the Edson site and YouTube channel are worth checking out for information about inspections. And it sounds like if you have any questions, both Will and Adam have made themselves available to give quick, reliable answers. We hope that helps. –Eds.

It is not just cable failure. I constantly hear (and read) of steering system failures on sailboats. I’ve heard and seen rack-and-pinion failing, hydraulic failing, self-steering wind vanes failing, gudgeon failing, electronic self-steering failing, single- and double-cable and chain system failures, tillers failing. Rudders themselves fall off or snap off. I’ve had some happen to me. When I teach sailing, I eventually get to teaching sailing without the rudder, and I think that is common practice. Because we all know that, if people sail much, they’ll eventually have to use that skill.

Obviously, none of these systems is designed to have the full unbuoyed weight of the boat fall against them. But that happens. Most are not designed to perform forever without maintenance. But that happens. Most are not designed to survive hull failure or flexure. But that happens. All are designed to survive very bad conditions, and without much regard to weight or cost. Well, even less regard for cost when weight is considered. That’s sailboats.

They appear to be designed as though lives depend upon them. And yet they each have been seen to fail at every point. Again, that’s sailboats.

I, too, don’t see why.

I would love to see a book, or a blog, detailing hundreds or thousands of sailboat steering failures. Especially if it was able to include, say, Edson’s and Lewmar’s vast knowledge of the subject.

–Isaiah Laderman

I broke a 25-year-old cable on a Tartan 40, but it took backing the rudder into something very hard on the bottom. That puts a very big turning force on the steering.

–James Doran

From my experience, nothing made of metal and exposed to saltwater or salt air has a long life aboard. As a retired airline and corporate pilot, I agree that the constant inspection of aircraft pieces and parts is also a factor.

–Joseph Haley

We have an ancient Morgan OI 41 that is steered by a cable system. I have no idea how old the cables are, but in the past 14 years we have owned the boat, we have had zero issues with the system. When we bought the boat, I inspected the cables by disconnecting them at the quadrant and pulling them back to the pedestal. (Of course, I had a small line attached so I could pull them back to the quadrant.) I did not find any meat hooks or rusted sections, so I reinstalled them. I suspect improper cable clamping or using the wrong cable are the main contributors to most cable failures. I have seen a lot of pulley failures, either the pulley rusted or the mounting pulled out. Use only high-grade aircraft control cable that is flexible. It can’t hurt to up-size the cable if your pulleys will handle it. Use saddle clamps instead of swages, it makes adjustment and repairs at sea much easier. Remember to have a length of cable and clamps on board to make repairs if something does break.

–John and Naomi Howard, Horizon, 1973 Morgan OI 41, Kadena Marina, Okinawa, Japan

I’ve owned my Catalina 30 (with Edson steering) for 32 years and have never replaced the steering cables. I occasionally spread winch grease on the cables and check for broken strands, but they still seem OK. But I’m nervous because I’ve had them so long and have considered replacing them anyway. Probably would do so if it were easier, not sure that “If it ain’t broke, don’t fix it” applies here because broken steering can be disastrous. It will be interesting to read what Edson has to say.

–Stan Galper

Hi Stan, we were impressed with the comprehensive answers we got from Edson and the invitations to readers to ask more questions of them. Sounds like it’s time to replace your cable and chain and look at your plate and it sounds like Edson is prepared to help you in any way. Best wishes. –Eds.

Distinctive Isla Ventana has long been used as a navigational aid by Sea of Cortez sailors. Raul Martinez III sent this photo from the 38^th annual running of the Spring Regatta in San Carlos, Mexico, hosted by the Tucson Sailing Club of Arizona, in which Isla Ventana is being used as a race marker.

DIY Blues

I’m wondering if other readers are having a similar experience. I have an old boat, 1966 Tartan 27. She has an A4 engine, she was built a long time before ABYC standards. I’m trying my best to do a refit, by myself. Trouble is, around the Chesapeake Bay, at least on the eastern shore of the Bay, marinas are deciding they don’t want people like me in their yard. I moved a couple of years ago from one marina when I was informed that I couldn’t work below the waterline, in other words, I couldn’t even paint my own bottom. I found another marina further down the Bay and was happily ensconced and working at my own pace. Suddenly the owner decides to sell. The buyer is a dealer in small boats and now has announced a similar policy. So I’m faced with moving again. But where?

–Bill Wilson, Good Old Boat subscriber

Hi Bill, we spoke to a manager of one Chesapeake Bay boatyard to get his take, below. Our personal experience (West Coast-based) echoes John’s comments. Ventura Boatyard (Ventura, California) is our favorite, but we know there are many others that welcome DIYers. After reading John’s comments, check out this link to reader feedback on their favorite DIY boatyards in the February 2019 issue of The Dogwatch: https://goodoldboat.com/mb-feb19/

***

Fear not, there are still boatyards on the Chesapeake who appreciate do-it-yourselfers.

In the yard I manage, we believe that the better informed boat owners are about their boats and systems, the happier they are. To that end, we encourage DIY boat owners and enjoy talking with them about their projects and helping them through their challenges. Our customers may work below the waterline, although if their sanding gear is inadequate to contain bottom-paint dust (as required by state regulation and to maintain good customer relations), we will rent our highly effective dustless sanding systems to solve that problem.

The most important thing when searching for a new yard is to be honest and direct with the yard manager. Tell him or her exactly what you are doing and how you intend to do it. In our yard, knowing someone is going to embark on a long-term restoration means we will place the boat in our long-term storage area close to power and water to help facilitate the project.

I know there are still yards on the Chesapeake and the Eastern Shore that allow do-it-yourselfers, even below the waterline. You may have to do some research via road trip to find them, as many remain small and family-owned and perhaps aren’t as well-advertised as the big yards.

–John Clarke, Operations Manager, Oak Harbor Marina, Rock Creek, Pasadena, Maryland

Bowditch Plug, Bowditch Remembrance

Nice to see the plug for Bowditch (Book Review, The Dogwatch, August 2019). My first Bowditch was a 1966 edition, an invaluable basic earth-science reference for me in environmental policy investigations for Congress in the late 1960s, and still useful in environmental policy studies into the 1980s.

–Gerald Schatz, J.D., Northport, Michigan

Like 30 years ago, I took celestial navigation at the Adler Planetarium here in Chicago. One evening, their chief librarian, wearing cotton gloves, brought out their second-edition (I think) Bowditch. The best parts were the scratch calculations on the flyleaves, where navigators 200 years ago had done their figuring. Very impressive.

–Chas. Hague, s/v Tangent

Sunrise, Sunset

Regarding the Nautical Trivia in last month’s The Dogwatch, one can also see the sun rise and set from Shacklelford Banks, Atlantic Beach, and Emerald Isle. All are southward-facing beaches on the North Carolina coast.

–Steve Addy

Second Favorite

We know that we publish the finest nationwide sailing magazine in Good Old Boat, that it’s the sailing magazine we, the staff, want to read, that it speaks to “the rest of us.” But we also know there are other great sailing magazines out there, so we were curious what Good Old Boat readers (and The Dogwatch readers), were also reading. So, we put it to the readers, in an online poll. Unfortunately, our list of mags/online periodicals to choose from was meant only as a sample of what’s out there, not a comprehensive list, and this wasn’t clear. So, we’ll do this again next year, and we’ll be more clear/comprehensive. In the meantime, below are the results from this imperfect poll, along with the write-in votes we got.

Even though it wasn’t the answer we were looking for (this was not intended as an exercise in self-congratulation), thank you to those of you who wrote in to let us know Good Old Boat is the only sailing periodical you read and there is no other. We’ll let John Fox speak for all of you folks in particular, and give him the first word, because he put Carly Simon and a great James Bond film into our heads…  –Eds.

***

I’m sorry, but I can’t answer your question; I don’t read anything but Good Old Boat. I’ve tried. But the alternatives contain either too much fluff, too many ads, or too much racing. I’ve pared down my reading of online sailing newsletters for the same reason; The Dogwatch is the only one. I just want to read about…well, what you already do. As the song goes, “Nobody does it better. Baby, you’re the best.”

–John Fox

Now, the poll results (just a hair shy of 200 votes), followed by a few more select comments. Thanks to write-in submitters that include: Chris Abrey, Chris Campbell, Jim Caskey, Peter Fallon, Marilyn Kinsey, George Lemmolo, Dana Mace, Craig Maumus, John Ross, and others. The write-in pubs are included in the poll results below, but each certainly would have received more votes if they’d been included in our click-options. We’ll get it right next year.

Latitudes & Attitudes: 25%

Cruising World: 16%

Latitude 38: 11%

Chesapeake Bay Magazine: 8%

Sailing Anarchy: 6%

SAIL: 6%

48 North: 5%

Ocean Navigator: 5%

Small Craft Advisor: 5%

Spinsheet: 4%

Practical Sailor: 2%

Pacific Yachting: 1%

BoatUS: 1%

Sailing: 1%

Soundings: 1%

SpinSheet: 1%

Wooden Boat: 1%

Off Center Harbor: .5%

Yachting Monthly: .5%

***

Back in the day it was Good Old Boat, Small Craft Advisor, and Wooden Boat. However, as I’ve aged I just don’t see myself taking on another large boat, one that will require moorage and/or dock fees and necessary refits, so I’ve had to let Gold Old Boat go. Small Craft Advisor has become my favorite go-to publication. Please don’t be offended, as Good Old Boat is outstanding! It’s just that the articles and boats within have outgrown my needs and abilities.

–Cecil Marmont, Stormbird, CP-16

My favorite sailing magazine (other than Good Old Boat) is Small Craft Advisor. The sailboat that owns me is a 1984 Starwind 19 by Wellcraft. Though somewhat smaller than most vessels normally included in Good Old Boat, its age necessitates restorative work and I will continue to benefit from the collective knowledge, wisdom, and creativity shared within the pages of Good Old Boat.

At 71, the sailing dream has not dissipated but has been somewhat downsized. It is through the pages of Good Old Boat that my dream is fueled and through the pages of Small Craft Advisor that my dream is kept “real.”

–Paul D. Bohac

Good Old Boat is my favorite and primary. I read almost nothing else, but I read Good Old Boat from cover to cover. I’ve read articles from Practical Sailor, which is very good. Some articles in BoatUS are good as well. But [those magazines] are very hit or miss.

–Bill Van Emburg

Next to Good Old Boat, my favorite sailing/boating magazine is Small Craft Advisor. I downsized from an Islander 28 to a trailersailer three years ago, a 1984 Com-Pac 19. Small Craft Advisor has lots of information and features that pertain to pocket cruisers. On the right is a photo from our vacation in Door County, Wisconsin, just after we bought her.

–Tony Rodriguez, Tulsa, Oklahoma

My favorite is Good Old Boat, mainly because of the articles on boat repair. I also enjoy the in-depth look at various boats, including the comparisons.

–John Ganann

The other sailing magazine is Sailing, from Port Washington, Wisconsin. Sailing has, among other things, Robert Perry reviews of new boats and designs, and good columns. My dad began subscribing way back in their black-and-white days and I have kept it up.

–Chris Campbell, Traverse City, Michigan

Click here to read more of September’s The Dogwatch.

Me Too!

Wow, so others have run into power lines too (“The Fourth of July Meltdown,” The Dogwatch, July 2019)! Around 1968, my brother and I set off across Lake Huron’s Saginaw Bay from Bay City to Sebewaing, our first real cruise on the new-to-our-family 1961 Seafarer Polaris, Baker’s Dozen (hull no. 13). I knew that at Sebewaing there was a power line across the river. I knew that everybody turned hard right into the little dredged basin by the airport. I knew there was a ’53 Chevy in the parking lot with keys so sailors and pilots could get into town for meals or groceries.

We navigated across the Bay and found the entrance channel at Sebewaing and headed in under power. At the basin entrance, I saw no power line overhead. What the heck? let’s power up the river for a look-see. And up we went until suddenly the bow began to rise gently. Uh-oh, I thought, we’ve run onto a mud bank. But just then the sparks started flying. I was standing in the companionway and hopped below. My brother, at the helm, figuring he was dead anyway, just froze. Only when he realized he wasn’t dead did he join me below. And there we were, huddled in fear, with the faithful outboard holding us against the power lines that somebody seemed to have moved.

After a while, we realized that the sparks had stopped. Topsides, we saw the spinnaker halyard tied off to the bow pulpit, keeping the spruce mast upright despite the forestay having burned through. That was extraordinarily lucky because that spruce mast is heavy.

We took the Chevy into town, bought a bunch of gas, and the next day we powered home with the faithful outboard. Then it was time for a new forestay.

Baker’s Dozen came to us in 1968 and I’m in the 52nd season of sailing my old friend. I’ve done a few dumb things in the years since, but nothing quite like running into the power lines.

–Chris Campbell, Good Old Boat subscriber

Seeking a Boat

For about a year now, I have had my nose to the ground looking for my grandfather’s boat, a 1984 or 1985 Marine Concepts Rob Roy 23. My dad is gearing up to retire and it would mean the world to him if he had his father’s boat to devote some time to. The search has proven a bit over my head.

The Rob Roy 23 had a very low production number (less than 90 hulls were made, I believe). I know that the boat was purchased new somewhere around 1984 or 1985 in Orleans, Massachusetts, and resold either to Nauset Marine or Aries Pond boatyard (both also in Orleans) in the late 1980s. She had a dark green hull with tanbark sails and was named Sygnet. The one photo I have of her shows what appears to be an after-market ventilation scoop, possibly evidencing an installed head.

I have contacted the above-named boatyards, as well as several private owners of Rob Roys and the state of Massachusetts, but nothing has turned up. I’m not quite ready to give up.

If anyone has any leads, please contact me at jackdodsworth1944@gmail.com.

–Jack Dodsworth, Solomons Island, Maryland

Summer Sailstice (or Sail Summerstice?)

We believe in Summer Sailstice, the worldwide annual celebration of sailing that was the brainchild of Latitude 38 publisher John Arndt. We think it’s important, getting people out sailing, hopefully taking the opportunity to introduce a non-sailor to sailing. So I put it to the readers, asking for your Summer Sailstice sailing story — and I promised to pick one story and send the writer a Good Old Boat hat.

Because he’s recently acquired his first good old boat and can therefore probably use some sun protection while sailing, we’re going to give Dirk Niles the first word…  –Eds.

***

Full disclosure: I had no idea June 22nd was Summer Sailstice. And yet, on June 22, my wife and I were on our maiden voyage aboard the first keelboat we’ve ever owned! We sailed with the sellers, who had lovingly sailed and maintained her (a 1981 C&C 34) for more than a decade. The weather forecast was crappy, but June 22 offered fantastic, sunny, breezy sailing weather! We reefed, practiced all the points of sail, docked with wind, everything! At dinner the sellers said our huge grins satisfied them that they’d found the right buyers.

–Dirk Niles, Great Joy, 1981 C&C 34

Approaching Craig, Alaska, we worriedly determined that something was wrong with our autopilot. The GPS said we were going one way. The autopilot said something else. Our reliable old magnetic compass had a third idea. It was foggy, with 1-mile visibility, but we were several miles offshore with boisterous seas in the Gulf of Alaska. I didn’t know what to trust.

We saw islands and rocks at the edge of the fog, but which ones were they? Going slowly, we watched the depth and listened for danger.

Later, safely in our anchorage, we traced out the wires to the autopilot’s fluxgate compass. Lo and behold, two days earlier a speaker had flown off a shelf and I’d chucked it into a locker for convenience. It was now just inches from the compass. Speakers have strong magnets…

Dilemma resolved and autopilot recommissioned, we left, unaware that Summer Sailstice was celebrated without us.

–Walter Heins, Golden Eagle

We held a raft up with the Clinton sailing club on Long Island Sound. Unfortunately, the wind was gusting 35-40 knots, so the few of us who made it motored more than sailed. And in these conditions, our planned raft-up proved impossible. We anchored close enough to enjoy some good company!

The sailing club has been hosting this event for past three Summer Sailstices! The first year was perfect, last year got rained out (we instead assembled at a Scottish Pub for some dark ‘n stormies), and this year we got what we got (which was fun!). Hopefully the weather is better next year!

–Lorie Eadie

Summer Sailstice weekend was a busy one, with three events planned over three days. The Friday night open house of our Fort Pierce Yacht Club. Saturday was a fun raft up. Sunday we watched the sinking of Voici Bernadette! Voici Bernadette is a small freighter that was cleaned up and sunk ten miles offshore to propagate a new reef. There was a post-sinking celebration.

We continued the Sailstice into July. The mayor of Fort Pierce, Florida, proclaimed July “Celebrate Our Waterways Month,” encouraging residents to join the Fort Pierce Yacht Club, “in celebrating the treasure of our waterways.” Then there was our annual boat parade (15 boats!) through the Intercoastal Waterway and our inlet to celebrate Independence Day.

–Joe Krivan
