American 25
Construction Details
| Designer | Arthur S. Henry |
|---|---|
| Builder | American Mariner Industries |
| Length | 25.000 ft |
| LOA | 25.000 ft |
| LWL | 23.000 ft |
| Beam | 7.980 ft |
| Displacement | 3500 lb |
| Ballast | 900 lb |
| Max Draft | 2.330 ft |
The standard boat dimensions
| i | 25 ft |
|---|---|
| j | 10.33 ft |
| p | 25 ft |
| e | 10.25 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 25 ft | 10.33 ft | 25 ft | 10.25 ft | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, P, and E)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 25 ft - (7620 mm) |
| Foot | * 10.25 ft - (3124 mm) |
| Leech | * 26.54 ft - (8089 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 26.69 ft - (8135 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | * 132.667 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 21.64 ft - (6596 mm) |
| Foot | * 14.41 ft - (4392 mm) |
| Leech | * 17.97 ft - (5477 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 11.88 ft - (3621 mm) |
| Deck Angle | * 12 ° |
| Area | * 128.53 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 25.7 ft - (7833 mm) |
| Foot | * 17.31 ft - (5276 mm) |
| Leech | * 23.75 ft - (7239 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 15.5 ft - (4724 mm) |
| Deck Angle | * 4 ° |
| Area | * 199.18 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 25.7 ft - (7833 mm) |
| Foot | * 17.04 ft - (5194 mm) |
| Leech | * 23.64 ft - (7205 mm) |
| Perc LP | * 165 % |
| Area | * 328.45 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
