The standard boat dimensions
| i | 31 ft |
|---|---|
| j | 10.30 ft |
| p | 25.50 ft |
| e | 8.50 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 31 ft | 10.30 ft | 25.50 ft | 8.50 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 31.03 ft - (9458 mm) |
| Foot | * 17 ft - (5182 mm) |
| Leech | * 28.55 ft - (8702 mm) |
| Perc LP | * 165 |
| Area | * 396 ft² |
| Sail Type | DRIFTER |
|---|---|
| Luff | * 31.03 ft - (9458 mm) |
| Foot | * 17.4 ft - (5304 mm) |
| Leech | * 27.73 ft - (8452 mm) |
| Perc LP | * 150 |
| Length Perp | * 15.45 |
| Deck Angle | * 9 ° |
| Area | * 239.71 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 17.97 ft - (5477 mm) |
| Foot | * 7.78 ft - (2371 mm) |
| Leech | * 14.61 ft - (4453 mm) |
| Perc LP | * 60 |
| Length Perp | * 6.18 |
| Deck Angle | * 19.06 ° |
| Area | * 55.5 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 25.5 ft - (7772 mm) |
| Foot | * 8.5 ft - (2591 mm) |
| Leech-AftHdBd | * 26.42 ft - (8053 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 26.6 ft - (8108 mm) |
| Head (inches) | * 4 in |
| Area (no Roach) | * 112.03 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 31.03 ft - (9458 mm) |
| Foot | * 16.71 ft - (5093 mm) |
| Leech | * 29.1 ft - (8870 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 15.45 ft - (4709 mm) |
| Deck Angle | * 4.03 ° |
| Area | * 239.68 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 26.13 ft - (7964 mm) |
| Foot | * 13.73 ft - (4185 mm) |
| Leech | * 22.56 ft - (6876 mm) |
| Percentage LP | * 115.05 % |
| Length Perpendicular | * 11.85 ft - (3612 mm) |
| Deck Angle | * 11.95 ° |
| Area | * 154.83 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 31.03 ft - (9458 mm) |
| MidGirth | * 18.54 ft - (5651 mm) |
| Foot | * 18.54 ft - (5651 mm) |
| Perc LP | * 180 |
| Area | * 489 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
