WESTSAIL 42 KETCH
Description
The WESTSAIL 42 KETCH is a sailboat designed by WIB Crealock.
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - | - |
Documents
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, P, and E)
WESTSAIL 42 KETCH - MAINSAIL
| Luff | 42 ft - (12802 mm) |
|---|---|
| Foot | 17.5 ft - (5334 mm) |
| Leech | * 44.47 ft - (13554 mm) |
| Tack Angle | * 87.36 ° |
| Diagonal | 44.75 ft - (13640 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 376.35 ft² |
| Edit in Calculator | |
WESTSAIL 42 KETCH - JIBSAIL
| Luff | 40 ft - (12192 mm) |
|---|---|
| Foot | 17 ft - (5182 mm) |
| Leech | 30 ft - (9144 mm) |
| Length Perpendicular | * 11.67 ft - (3557 mm) |
| Area | * 233.38 ft² |
| Edit in Calculator | |
WESTSAIL 42 KETCH - STAYSAIL
| Luff | 35 ft - (10668 mm) |
|---|---|
| Foot | 10 ft - (3048 mm) |
| Leech | 32 ft - (9754 mm) |
| Length Perpendicular | * 9.03 ft - (2752 mm) |
| Area | * 158 ft² |
| Edit in Calculator | |
WESTSAIL 42 KETCH - MIZZEN
| Luff | 29 ft - (8839 mm) |
|---|---|
| Foot | 9 ft - (2743 mm) |
| Leech-AftHdBd | * 30.71 ft - (9360 mm) |
| Tack Ang | * 94.42 ° |
| Diag (clew/head) | * 31.02 ft - (9455 mm) |
| Head (inches) | 4.5 in - (114 mm) |
| Area (no Roach) | * 133.37 ft² |
| Edit in Calculator | |
