Seaward Fox 17
Description
The SEAWARD Fox 17 is a dinghy designed by Nick Hake. This pocket cruiser packs surprising capability into a small package, Her generous sail plan delivers excellent light-air performance. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Nick Hake |
|---|---|
| Length | 17.000 ft |
| LOA | 19.750 ft |
| LWL | 14.830 ft |
| Beam | 8.000 ft |
| Displacement | 1300 lb |
| Max Draft | 1.580 ft |
The standard boat dimensions
| i | 19 ft |
|---|---|
| j | 5.50 ft |
| p | 17 ft |
| e | 8.75 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 19 ft | 5.50 ft | 17 ft | 8.75 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 17 ft - (5182 mm) |
| Foot | * 8.75 ft - (2667 mm) |
| Leech-AftHdBd | * 18.65 ft - (5685 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 18.85 ft - (5745 mm) |
| Head (inches) | * 4 in |
| Area (no Roach) | * 76.83 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 18.75 ft - (5715 mm) |
| Foot | 6.083 ft - (1854 mm) |
| Leech | 17 ft - (5182 mm) |
| Percentage LP | * 99.45 % |
| Length Perpendicular | * 5.47 ft - (1667 mm) |
| Deck Angle | * 9.73 ° |
| Area | * 51.31 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 15.82 ft - (4822 mm) |
| Foot | * 7.17 ft - (2185 mm) |
| Leech | * 13.95 ft - (4252 mm) |
| Percentage LP | * 114.91 % |
| Length Perpendicular | * 6.32 ft - (1926 mm) |
| Deck Angle | * 12.02 ° |
| Area | * 50 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 18.79 ft - (5727 mm) |
| Foot | * 8.79 ft - (2679 mm) |
| Leech | * 17.79 ft - (5422 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 8.25 ft - (2515 mm) |
| Deck Angle | * 4.02 ° |
| Area | * 77.52 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 18.79 ft - (5727 mm) |
| Foot | * 9.07 ft - (2765 mm) |
| Leech | * 17.29 ft - (5270 mm) |
| Perc LP | * 165 % |
| Area | * 128 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 18.79 ft - (5727 mm) |
| MidGirth | * 9.9 ft - (3018 mm) |
| Foot | * 9.9 ft - (3018 mm) |
| Perc LP | * 180 % |
| Area | * 158 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
