Sagitta 30
Description
The Sagita 30 is a 30-foot performance cruiser designed by Judel/Vrolijk & Co and built by Hanse Yachts in Germany from 2008 to 2012. This model represents Hanse's venture into the performance-oriented sailing market, featuring a modern hull design with chined topsides and a distinctive plumb bow that maximizes waterline length for enhanced speed potential. Built using vacuum-infused fiberglass construction with foam core sandwich in the topsides and solid laminate below the waterline, the boat incorporates a cast iron fin keel with lead bulb and spade rudder configuration optimized for performance sailing. Production was limited during its four-year run, with approximately 150-200 units built before Hanse discontinued the model to focus on their more traditional cruising-oriented designs.
Construction Details
| Designer | Judel/Vrolijk & Co. |
|---|---|
| Builder | Hanse Yachts (Germany) |
| Length | 30.020 ft |
| LOA | 30.180 ft |
| LWL | 7.890 ft |
| Beam | 9.840 ft |
| Displacement | 7716 lb |
| Ballast | 2866 lb |
| Max Draft | 5.580 ft |
| Year Built | 2008 |
The standard boat dimensions
| i | 36.50 ft |
|---|---|
| j | 12.40 ft |
| p | 33 ft |
| e | 9.50 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 36.50 ft | 12.40 ft | 33 ft | 9.50 ft | - | - | - | - |
Sails
Sagitta 30 - MAINSAIL
| Luff | * 33 ft - (10058 mm) |
|---|---|
| Foot | * 9.5 ft - (2896 mm) |
| Leech | * 33.82 ft - (10308 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 34.02 ft - (10369 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | * 162.03 ft² |
| Edit in Calculator |
Sagitta 30 - GENOA
| Luff | * 36.62 ft - (11162 mm) |
|---|---|
| Foot | * 20.17 ft - (6148 mm) |
| Leech | * 34.3 ft - (10455 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 18.6 ft - (5669 mm) |
| Deck Angle | * 3.99 ° |
| Area | * 340.57 ft² |
| Edit in Calculator |
Sagitta 30 - SPINNAKER
| Stays | * 36.62 ft - (11162 mm) |
|---|---|
| MidGirth | * 22.32 ft - (6803 mm) |
| Foot | * 22.32 ft - (6803 mm) |
| Perc LP | * 180 % |
| Area | * 695 ft² |
| Edit in Calculator |
Sagitta 30 - STAYSAIL
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
