Roberts Spray 40 (Version C)
Description
The Bruce Roberts Spray 40 Version C is a heavy-displacement, pilothouse ketch (or cutter variant) designed by Bruce Roberts in the 1970s–1980s, inspired by Joshua Slocum's legendary 1900 circumnavigator Spray, and offered as affordable plans for amateur or professional builders in steel, aluminum, or fiberglass—prioritizing ultimate seaworthiness, shallow-draft versatility with bilge keels, and cozy liveaboard comfort for solo or family bluewater cruising. Version C specifically features a robust multi-chine hull for easy construction, a protected pilothouse for all-weather helm, and flexible sail plans like Chinese lug or gaff rigging for simple handling, accommodating 4–6 in a single spacious cabin with U-galley, saloon settees, and en-suite head—proven in passages from the Atlantic to Pacific, though its ponderous weight makes it more motorsailer than pure sailer. With over 200 completed worldwide, it's a budget-friendly tank of a boat for extended voyages
Construction Details
| Designer | Bruce Roberts-Goodson |
|---|---|
| Length | 40.000 ft |
| LWL | 16.570 ft |
| Beam | 7.083 ft |
| Max Draft | 3.600 ft |
| Min Draft | 0.803 ft |
The standard boat dimensions
| i | 41.50 ft |
|---|---|
| j | 20.33 ft |
| p | 41.50 ft |
| e | 13.92 ft |
| p2 | 24 ft |
| e2 | 9.75 ft |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 41.50 ft | 20.33 ft | 41.50 ft | 13.92 ft | 24 ft | 9.75 ft | - | - |
Documents
Sails
Roberts Spray 40 (Version C) - MAINSAIL
| Luff | * 41.5 ft - (12649 mm) |
|---|---|
| Foot | * 13.92 ft - (4243 mm) |
| Leech | * 43.15 ft - (13152 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 43.31 ft - (13201 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 288.52 ft² |
| Edit in Calculator | |
Roberts Spray 40 (Version C) - JIBSAIL
| Luff | * 36.97 ft - (11268 mm) |
|---|---|
| Foot | * 29.71 ft - (9056 mm) |
| Leech | * 29.9 ft - (9114 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 23.38 ft - (7126 mm) |
| Deck Angle | * 12 ° |
| Area | 432.18 ft² |
| Edit in Calculator | |
Roberts Spray 40 (Version C) - GENOA
| Luff | * 43.9 ft - (13381 mm) |
|---|---|
| Foot | * 35.25 ft - (10744 mm) |
| Leech | * 40.22 ft - (12259 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 30.5 ft - (9296 mm) |
| Deck Angle | * 4 ° |
| Area | 669.4 ft² |
| Edit in Calculator | |
Roberts Spray 40 (Version C) - SPINNAKER
| Stays | * 43.9 ft - (13381 mm) |
|---|---|
| MidGirth | * 36.59 ft - (11153 mm) |
| Foot | * 36.59 ft - (11153 mm) |
| Perc LP | * 180 % |
| Area | 1365.36 ft² |
| Edit in Calculator | |
Roberts Spray 40 (Version C) - MIZZEN
| Luff | * 24 ft - (7315 mm) |
|---|---|
| Foot | * 9.75 ft - (2972 mm) |
| Leech-AftHdBd | * 25.59 ft - (7800 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 25.59 ft - (7800 mm) |
| Head (inches) | * 4 in - (102 mm) |
| Area (no Roach) | * 120.34 ft² |
| Edit in Calculator | |
