Roberts Spray 22 Yawl
Description
The Bruce Roberts Spray 22 in its yawl-rigged variant—designed by Bruce Roberts-Goodson in 1974 as a trailerable pocket cruiser inspired by Joshua Slocum's legendary Spray—is a compact, seaworthy daysailer and weekender prized for its traditional aesthetics, balanced handling, and versatility in shallow waters or coastal hops, with over 800 examples built worldwide, some configured as yawls for enhanced sail balance and reduced weather helm. The yawl setup places the small mizzen mast aft of the rudder post, allowing the main to be fully reefed without losing steering authority, while maintaining the buoyant multi-chine hull's forgiving stability and light-air responsiveness; available in fixed keel or centerboard versions for easy trailering (under 3,500 lb), it supports DIY construction in steel/aluminum (multi-chine), fiberglass (round bilge with C-Flex or foam core), or wood-epoxy, with cozy accommodations for 2–4 berths in a trunk cabin layout, powered by a 4–6 hp outboard, and build costs around $10,000–$15,000.
The standard boat dimensions
| i | 26.67 ft |
|---|---|
| j | 9.75 ft |
| p | 22.50 ft |
| e | 8 ft |
| p2 | 13 ft |
| e2 | 5 ft |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 26.67 ft | 9.75 ft | 22.50 ft | 8 ft | 13 ft | 5 ft | - | - |
Documents
Sails
Roberts Spray 22 Yawl - MAINSAIL
| Luff | * 22.5 ft - (6858 mm) |
|---|---|
| Foot | * 8 ft - (2438 mm) |
| Leech | * 23.52 ft - (7169 mm) |
| Tack Angle | * 88.03 ° |
| Diagonal | * 23.62 ft - (7199 mm) |
| Head (inches) | * 3.5 in - (89 mm) |
| Area | 89.9 ft² |
| Edit in Calculator | |
Roberts Spray 22 Yawl - JIBSAIL
| Luff | * 22.72 ft - (6925 mm) |
|---|---|
| Foot | * 13.23 ft - (4033 mm) |
| Leech | * 19.29 ft - (5880 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 11.21 ft - (3417 mm) |
| Deck Angle | * 12 ° |
| Area | 127.37 ft² |
| Edit in Calculator | |
Roberts Spray 22 Yawl - GENOA
| Luff | * 26.98 ft - (8224 mm) |
|---|---|
| Foot | * 16.02 ft - (4883 mm) |
| Leech | * 25.14 ft - (7663 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 14.63 ft - (4459 mm) |
| Deck Angle | * 4 ° |
| Area | 197.32 ft² |
| Edit in Calculator | |
Roberts Spray 22 Yawl - SPINNAKER
| Stays | * 26.98 ft - (8224 mm) |
|---|---|
| MidGirth | * 17.55 ft - (5349 mm) |
| Foot | * 17.55 ft - (5349 mm) |
| Perc LP | * 180 % |
| Area | 402.47 ft² |
| Edit in Calculator | |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
