Roberts Pcf 40
Description
The ROBERTS PCF 40 is a sailboat. Her generous sail plan delivers excellent light-air performance.
The standard boat dimensions
| i | 27.50 ft |
|---|---|
| j | 16.50 ft |
| p | 21.58 ft |
| e | 14.50 ft |
| p2 | 19.83 ft |
| e2 | 8 ft |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 27.50 ft | 16.50 ft | 21.58 ft | 14.50 ft | 19.83 ft | 8 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, P, and E)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 21.58 ft - (6578 mm) |
| Foot | * 14.5 ft - (4420 mm) |
| Leech | * 25.3 ft - (7711 mm) |
| Tack Angle | * 88.02 ° |
| Diagonal | * 25.58 ft - (7797 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 156.2 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 25.66 ft - (7821 mm) |
| Foot | * 25.93 ft - (7903 mm) |
| Leech | * 20.59 ft - (6276 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 18.98 ft - (5785 mm) |
| Deck Angle | * 12 ° |
| Area | 243.47 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 30.47 ft - (9287 mm) |
| Foot | * 30.2 ft - (9205 mm) |
| Leech | * 28.03 ft - (8544 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 24.75 ft - (7544 mm) |
| Deck Angle | * 4 ° |
| Area | 377.03 ft² |
| Sail Type | MIZZEN |
|---|---|
| Luff | * 19.83 ft - (6044 mm) |
| Foot | * 8 ft - (2438 mm) |
| Leech-AftHdBd | * 21.01 ft - (6404 mm) |
| Tack Ang | * 87.98 ° |
| Diag (clew/head) | * 21.12 ft - (6437 mm) |
| Head (inches) | * 3.5 in - (89 mm) |
| Area (no Roach) | 79.22 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
