ROBERTS NORFOLK 43
Description
The ROBERTS NORFOLK 43 is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 43.000 ft |
The standard boat dimensions
| i | 51.92 ft |
|---|---|
| j | 17.92 ft |
| p | 45.33 ft |
| e | 14.17 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 51.92 ft | 17.92 ft | 45.33 ft | 14.17 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 45.33 ft - (13817 mm) |
| Foot | * 14.17 ft - (4319 mm) |
| Leech-AftHdBd | * 46.87 ft - (14286 mm) |
| Tack Ang | * 88.01 ° |
| Diag (clew/head) | * 47.02 ft - (14332 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 320.83 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 52.18 ft - (15904 mm) |
| Foot | * 29.21 ft - (8903 mm) |
| Leech | * 48.81 ft - (14877 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 26.88 ft - (8193 mm) |
| Deck Angle | * 4 ° |
| Area | 701.24 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 43.94 ft - (13393 mm) |
| Foot | * 24.05 ft - (7330 mm) |
| Leech | * 37.67 ft - (11482 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 20.61 ft - (6282 mm) |
| Deck Angle | * 12 ° |
| Area | 452.67 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 52.18 ft - (15904 mm) |
| MidGirth | * 32.26 ft - (9833 mm) |
| Foot | * 32.26 ft - (9833 mm) |
| Perc LP | * 180 |
| Area | 1430.83 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
