ROBERTS 57
Description
The ROBERTS 57 is a sailboat.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 57.000 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | 47.08 ft |
| e | 20.75 ft |
| p2 | 40 ft |
| e2 | 13.42 ft |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | 47.08 ft | 20.75 ft | 40 ft | 13.42 ft |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 47.08 ft - (14350 mm) |
| Foot | * 20.75 ft - (6325 mm) |
| Leech-AftHdBd | * 50.58 ft - (15417 mm) |
| Tack Ang | * 87.99 ° |
| Diag (clew/head) | * 50.78 ft - (15478 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 487.95 ft² |
| Sail Type | MIZZEN |
|---|---|
| Luff | * 40 ft - (12192 mm) |
| Foot | * 13.42 ft - (4090 mm) |
| Leech-AftHdBd | * 41.59 ft - (12677 mm) |
| Tack Ang | * 88.02 ° |
| Diag (clew/head) | * 41.75 ft - (12725 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | 268.1 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
