Roberts 434 A,B,C,D
Description
The Bruce Roberts 434, introduced in 2000 by Australian naval architect Bruce Roberts, is a heavy-displacement bluewater cruising sailboat celebrated for its robust construction, spacious liveaboard accommodations, and proven offshore capability, with hundreds built worldwide by owner-enthusiasts. Optimized for long-distance voyages or coastal exploration, it features a moderate fin keel (deep or shoal draft) with skeg-hung rudder for stability and tracking, and a center-cockpit layout for protected steering. Variants A (Sloop - Aft Cockpit), B (Cutter - Center Cockpit), C (Ketch -Pilot House or Center Cockpit), and D (Sloop - flush deck with raised aft cabin primarily differ in rig configuration (sloop, cutter, ketch) and deck styling (low-profile aft cockpit, center cockpit, pilothouse, or flush deck with raised aft cabin), allowing customization for short-handed sailing or family cruising. Built in multi-chine or radius-chine steel/aluminum (unsinkable, heavier), round-bilge fiberglass, or wood/epoxy (lighter, smoother), the 434 offers three cabins with 6 fixed berths, two heads (one en-suite), a U-galley, nav station, and ample storage for provisions—headroom exceeds 6'4" in the saloon. Proven in single-handed circumnavigations (e.g., 27,000 miles in 218 days), it sustains 9–10 knots with excellent directional stability, handling knockdowns and broaches with ease.
Construction Details
| Designer | Bruce Roberts-Goodson |
|---|---|
| Length | 43.000 ft |
| LWL | 16.570 ft |
| Beam | 7.083 ft |
| Max Draft | 3.600 ft |
| Min Draft | 0.803 ft |
The standard boat dimensions
| i | 53 ft |
|---|---|
| j | 17 ft |
| p | 46 ft |
| e | 18 ft |
| p2 | 20 ft |
| e2 | 18 ft |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 53 ft | 17 ft | 46 ft | 18 ft | 20 ft | 18 ft | - | - |
Documents
Sails
Roberts 434 A,B,C,D - MAINSAIL
| Luff | * 46 ft - (14021 mm) |
|---|---|
| Foot | * 18 ft - (5486 mm) |
| Leech | * 48.63 ft - (14822 mm) |
| Tack Angle | * 88.01 ° |
| Diagonal | * 48.81 ft - (14877 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 413.57 ft² |
| Edit in Calculator | |
Roberts 434 A,B,C,D - JIBSAIL
| Luff | * 44.53 ft - (13573 mm) |
|---|---|
| Foot | * 22.53 ft - (6867 mm) |
| Leech | * 38.65 ft - (11781 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 19.55 ft - (5959 mm) |
| Deck Angle | * 12 ° |
| Area | 435.37 ft² |
| Edit in Calculator | |
Roberts 434 A,B,C,D - GENOA
| Luff | * 52.88 ft - (16118 mm) |
|---|---|
| Foot | * 27.46 ft - (8370 mm) |
| Leech | * 49.73 ft - (15158 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 25.5 ft - (7772 mm) |
| Deck Angle | * 4 ° |
| Area | 674.24 ft² |
| Edit in Calculator | |
Roberts 434 A,B,C,D - SPINNAKER
| Stays | * 52.88 ft - (16118 mm) |
|---|---|
| MidGirth | * 30.6 ft - (9327 mm) |
| Foot | * 30.6 ft - (9327 mm) |
| Perc LP | * 180 % |
| Area | 1375.41 ft² |
| Edit in Calculator | |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
