Roberts 31

Roberts 31

Description

The Bruce Roberts 31, a classic fiberglass cruising sailboat designed by Australian naval architect Bruce Roberts in the 1970s for owner-builders seeking seaworthy coastal and moderate offshore capability, has seen over 100 examples constructed worldwide, celebrated for its multi-chine hull, gaff cutter rig, and versatile accommodations in a compact package ideal for solo sailors, couples, or small families. Measuring 31 feet 11 inches LOA with a 24-foot-2-inch LWL, 10-foot beam, 4-foot-6-inch draft on a long keel for stability, and a displacement of 14,200 pounds, this vessel offers an estimated sail area of around 500 square feet across mainsail and headsails for efficient performance in 10-25 knot winds, achieving 5.5-7 knot hull speeds with responsive handling, complemented by a 20- to 30-horsepower auxiliary diesel like the Yanmar 3GM. Its traditional lines feature a clipper bow, moderate sheer, and trunk cabin options, paired with a cozy interior boasting 6-foot headroom, layouts for four to six berths including V-berth forward, saloon settee, quarter berth aft, compact galley, and enclosed head, plus modest tankage of 40-60 gallons fuel and water for weekend-to-weeklong autonomy. Proven in ambitious voyages—from Australian waters to Japan, China, Canada, and trans-U.S. passages—as in early builds like those documented in Roberts' plans, the 31 delivers big-boat virtues of durability and satisfaction in a trailerable, budget-friendly design, remaining a staple for aspiring cruisers valuing simplicity and adventure.

Construction Details

Designer Bruce Roberts-Goodson
Length 31.000 ft
Request A Sail Quote

The standard boat dimensions

i 37.75 ft
j 14.50 ft
p 33.50 ft
e 14 ft
p2 -
e2 -
i2 -
j2 -

Blueprints

Sails

Roberts 31 - MAINSAIL

Luff * 33.5 ft - (10211 mm)
Foot * 14 ft - (4267 mm)
Leech * 35.66 ft - (10869 mm)
Tack Angle * 87.98 °
Diagonal * 35.85 ft - (10927 mm)
Head (inches) * 6 in - (152 mm)
Area 234.21 ft²
Edit in Calculator

Roberts 31 - SPINNAKER

Stays * 38.42 ft - (11710 mm)
MidGirth * 26.1 ft - (7955 mm)
Foot * 26.1 ft - (7955 mm)
Perc LP * 180 %
Area 852.35 ft²
Edit in Calculator

Roberts 31 - YANKEE

Luff 36 ft - (10973 mm)
Foot 15.19 ft - (4630 mm)
Leech 26.58 ft - (8102 mm)
Length Perpendicular 10.05 ft - (3063 mm)
Area 180.86 ft²
Edit in Calculator

Roberts 31 - STAYSAIL

Luff 28.5 ft - (8687 mm)
Foot 10.83 ft - (3301 mm)
Leech 25.5 ft - (7772 mm)
Length Perpendicular 9.66 ft - (2944 mm)
Area 137.63 ft²
Edit in Calculator

Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
