Roberts 22 Trailer Sailer (Adventurer)
Description
The Bruce Roberts Adventurer 22, also known as the Spray 22 or TS 22, is a compact, trailerable pocket cruiser designed by Bruce Roberts-Goodson in the 1970s, celebrated for its seaworthy yet lightweight hull that balances performance in light airs with family-friendly accommodations, making it a staple for coastal day sails, gunkholing, or weekend overnights with over 500 built worldwide as an accessible DIY project. Available in centerboard (for shallow draft versatility), fixed shoal keel (for stability), or bilge keel versions, it supports straightforward construction in fiberglass (C-Flex, single skin, or foam sandwich) or cold-molded wood-epoxy, delivering responsive handling under a generous Bermudan sloop rig ideal for single-handing or beginners, with plans including full-size patterns, material lists, accommodation layouts (trunk cabin or motorsailer), and sail/rig details for builds under $10,000–$15,000 total.
The standard boat dimensions
| i | 28.50 ft |
|---|---|
| j | 8.33 ft |
| p | 24.75 ft |
| e | 9.75 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 28.50 ft | 8.33 ft | 24.75 ft | 9.75 ft | - | - | - | - |
Documents
Blueprints
Sails
Roberts 22 Trailer Sailer (Adventurer) - MAINSAIL
| Luff | * 24.75 ft - (7544 mm) |
|---|---|
| Foot | * 9.75 ft - (2972 mm) |
| Leech | * 26.07 ft - (7946 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 26.28 ft - (8010 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | * 124.65 ft² |
| Edit in Calculator | |
Roberts 22 Trailer Sailer (Adventurer) - JIBSAIL
| Luff | * 23.75 ft - (7239 mm) |
|---|---|
| Foot | * 10.88 ft - (3316 mm) |
| Leech | * 20.92 ft - (6376 mm) |
| Percentage LP | * 115.01 % |
| Length Perpendicular | * 9.58 ft - (2920 mm) |
| Deck Angle | * 11.98 ° |
| Area | * 113.79 ft² |
| Edit in Calculator | |
Roberts 22 Trailer Sailer (Adventurer) - GENOA
| Luff | 28.67 ft - (8739 mm) |
|---|---|
| Foot | 8.42 ft - (2566 mm) |
| Leech | 26.42 ft - (8053 mm) |
| Percentage LP | * 92.44 % |
| Length Perpendicular | * 7.7 ft - (2347 mm) |
| Deck Angle | * 7.51 ° |
| Area | * 110.43 ft² |
| Edit in Calculator | |
Roberts 22 Trailer Sailer (Adventurer) - ASYMMETRICAL
| Luff | * 28.21 ft - (8598 mm) |
|---|---|
| Foot | * 13.74 ft - (4188 mm) |
| Leech | * 25.95 ft - (7910 mm) |
| Perc LP | * 165 % |
| Area | * 291 ft² |
| Edit in Calculator | |
Roberts 22 Trailer Sailer (Adventurer) - SPINNAKER
| Stays | * 28.21 ft - (8598 mm) |
|---|---|
| MidGirth | * 14.99 ft - (4569 mm) |
| Foot | * 14.99 ft - (4569 mm) |
| Perc LP | * 180 % |
| Area | * 359 ft² |
| Edit in Calculator | |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
