Roberts 19
Description
The Bruce Roberts 19 is a compact, trailerable pocket cruiser designed in 1974 by naval architect Bruce Roberts-Goodson, offering detailed plans for affordable amateur construction in steel, aluminum, fiberglass, or wood epoxy, tailored for coastal day sails, weekend escapes, or introductory bluewater forays with solo sailors or small families seeking simplicity and seaworthiness. At 19 feet 3 inches LOA with a 7-foot 1-inch beam, shallow draft (centerboard up 10 inches, down 3 feet 7 inches), and light trailerable displacement around 1,850-1,883 pounds, its broad, flat-bottomed hull with twin keels provides buoyant stability in chop, while a generous fractional sloop rig (I=23.3 ft, J=8.3 ft, P=20.1 ft, E=8.0 ft) supports effective light-air performance up to moderate breezes, though it thrives best over 10 knots and may require motoring in calms due to a sail area/displacement ratio near 16. Belowdecks, the snug interior fits two comfortably in a forward V-berth and convertible saloon settees, augmented by a minimal galley and portable head, making it a forgiving starter boat that's easy to maintain and customize.
Construction Details
| Designer | Bruce Roberts-Goodson |
|---|---|
| Length | 19.000 ft |
| LWL | 16.570 ft |
| Beam | 7.083 ft |
| Max Draft | 3.600 ft |
| Min Draft | 0.803 ft |
The standard boat dimensions
| i | 23.25 ft |
|---|---|
| j | 8.25 ft |
| p | 20.08 ft |
| e | 8 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 23.25 ft | 8.25 ft | 20.08 ft | 8 ft | - | - | - | - |
Documents
Sails
Roberts 19 - MAINSAIL
| Luff | * 20.08 ft - (6120 mm) |
|---|---|
| Foot | * 8 ft - (2438 mm) |
| Leech | * 21.19 ft - (6459 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 21.35 ft - (6507 mm) |
| Head (inches) | * 3.5 in - (89 mm) |
| Area | * 82.86 ft² |
| Edit in Calculator | |
Roberts 19 - JIBSAIL
| Luff | 22 ft - (6706 mm) |
|---|---|
| Foot | 8.75 ft - (2667 mm) |
| Leech | 19.75 ft - (6020 mm) |
| Percentage LP | * 95.15 % |
| Length Perpendicular | * 7.85 ft - (2393 mm) |
| Deck Angle | * 6.75 ° |
| Area | * 86.3 ft² |
| Edit in Calculator | |
Roberts 19 - JIBSAIL
| Luff | 22 ft - (6706 mm) |
|---|---|
| Foot | 10.67 ft - (3252 mm) |
| Leech | 20.5 ft - (6248 mm) |
| Percentage LP | * 119.76 % |
| Length Perpendicular | * 9.88 ft - (3011 mm) |
| Deck Angle | * 2.69 ° |
| Area | * 108.65 ft² |
| Edit in Calculator | |
Roberts 19 - JIBSAIL
| Luff | * 19.74 ft - (6017 mm) |
|---|---|
| Foot | * 11.13 ft - (3392 mm) |
| Leech | * 16.85 ft - (5136 mm) |
| Percentage LP | * 115.03 % |
| Length Perpendicular | * 9.49 ft - (2893 mm) |
| Deck Angle | * 11.97 ° |
| Area | * 93.66 ft² |
| Edit in Calculator | |
Roberts 19 - GENOA
| Luff | 21 ft - (6401 mm) |
|---|---|
| Foot | 8 ft - (2438 mm) |
| Leech | 18.58 ft - (5663 mm) |
| Percentage LP | * 85.33 % |
| Length Perpendicular | * 7.04 ft - (2146 mm) |
| Deck Angle | * 8.86 ° |
| Area | * 73.89 ft² |
| Edit in Calculator | |
Roberts 19 - GENOA
| Luff | * 23.44 ft - (7145 mm) |
|---|---|
| Foot | * 13.5 ft - (4115 mm) |
| Leech | * 21.89 ft - (6672 mm) |
| Percentage LP | * 150.06 % |
| Length Perpendicular | * 12.38 ft - (3773 mm) |
| Deck Angle | * 3.98 ° |
| Area | * 145.08 ft² |
| Edit in Calculator | |
Roberts 19 - ASYMMETRICAL
| Luff | 24 ft - (7315 mm) |
|---|---|
| Foot | 14 ft - (4267 mm) |
| Leech | 22 ft - (6706 mm) |
| Perc LP | * 165 % |
| Area | * 252 ft² |
| Edit in Calculator | |
