PDQ 32
Description
The PDQ 32 is a compact, lightweight cruising catamaran designed by Alan Slater and built by PDQ Yachts Inc. (Whitby, Ontario, Canada) from 1994/1995 to around 2002–2003. It features fiberglass construction with vacuum-bagged Core-Cell foam core (plus triaxial cloth, AME 5000 epoxy resin, and carbon fiber in the main beam for strength and weight savings), twin mini-keels (no daggerboards), a masthead sloop rig, twin outboard auxiliary power (typically 2 × 9.9 hp Yanmar or similar), and a bridgedeck layout emphasizing bright, airy accommodations (two hull cabins plus salon, good headroom up to 6'11" in open areas, and protection in the cockpit). Intended as a performance-oriented yet comfortable pocket cruiser (a smaller sibling to the popular PDQ 36), it offers quick acceleration, good upwind ability (tacks through <90° in some reports), easy shorthanded sailing, and solid seaworthiness for coastal/bluewater use without excessive weight or cost. Production totaled 53 hulls over about eight years, now long out of production but with a strong used-market following and reputation for quality, speed, and value.
Construction Details
| Designer | Alan Slater |
|---|---|
| Builder | PDQ Yachts (Whitby, Ontario) |
| Length | 31.580 ft |
| LOA | 31.580 ft |
| LWL | 31.000 ft |
| Beam | 16.000 ft |
| Displacement | 7200 lb |
| Max Draft | 2.500 ft |
| Year Built | 1994 |
The standard boat dimensions
| i | 46.25 ft |
|---|---|
| j | 11.08 ft |
| p | 38.67 ft |
| e | 13.50 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 46.25 ft | 11.08 ft | 38.67 ft | 13.50 ft | - | - | - | - |
Sails
PDQ 32 - MAINSAIL
| Luff | * 38.67 ft - (11787 mm) |
|---|---|
| Foot | * 13.5 ft - (4115 mm) |
| Leech | * 40.24 ft - (12265 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 40.51 ft - (12347 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 269.36 ft² |
| Edit in Calculator |
PDQ 32 - GENOA
| Luff | 39.67 ft - (12091 mm) |
|---|---|
| Foot | 19.5 ft - (5944 mm) |
| Leech | 36.5 ft - (11125 mm) |
| Percentage LP | * 155.3 % |
| Length Perpendicular | * 17.86 ft - (5444 mm) |
| Deck Angle | * 8.03 ° |
| Area | * 354.18 ft² |
| Edit in Calculator |
PDQ 32 - ASYMMETRICAL
| Luff | 46.75 ft - (14249 mm) |
|---|---|
| Foot | 21 ft - (6401 mm) |
| Leech | 44 ft - (13411 mm) |
| Perc LP | * 165 % |
| Area | * 736 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
