Hagar 28 (Cutter Rig)
Description
The Hagar 28 (also styled as HAGAR) is a compact, diesel-powered junk-rigged cutter designed by American naval architect George Buehler for amateur or professional construction, emphasizing simplicity, seaworthiness, and low-cost offshore cruising in a trailerable package. Introduced in the 1990s as part of Buehler's "Diesel Duck"-inspired series of practical, no-frills voyagers, it's built with steel hull (below waterline) and plywood/steel superstructure, often owner-completed for budgets under $50,000 (historical estimates). Buehler later updated the design into the Emily 28, recommending it over Hagar for improved stiffness and interior volume, but several Hagars were built and launched (e.g., one in Port Angeles, WA, in 2011).
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - | - |
Sails
Hagar 28 (Cutter Rig) - MAINSAIL
| Luff | 26.42 ft - (8053 mm) |
|---|---|
| Foot | 13 ft - (3962 mm) |
| Leech | * 28.82 ft - (8784 mm) |
| Tack Angle | * 88.02 ° |
| Diagonal | * 29.04 ft - (8851 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 171.49 ft² |
| Edit in Calculator | |
Hagar 28 (Cutter Rig) - YANKEE
| Luff | 26.67 ft - (8129 mm) |
|---|---|
| Foot | 12 ft - (3658 mm) |
| Leech | 19.5 ft - (5944 mm) |
| Length Perpendicular | 8.04 ft - (2451 mm) |
| Area | 107.25 ft² |
| Edit in Calculator | |
Hagar 28 (Cutter Rig) - STAYSAIL
| Luff | 23.17 ft - (7062 mm) |
|---|---|
| Foot | 10.83 ft - (3301 mm) |
| Leech | 19.5 ft - (5944 mm) |
| Length Perpendicular | 9.08 ft - (2768 mm) |
| Area | 105.13 ft² |
| Edit in Calculator | |
