Gulfstar 53 Sloop
Description
The GULFSTAR 53 SLOOP is a luxury yacht designed by V.S. Lazzara. This substantial yacht offers spacious accommodations and excellent seakeeping, Her generous sail plan delivers excellent light-air performance. Built for luxury cruising anywhere in the world with style and comfort.
Construction Details
Designer | V.S. Lazzara |
---|---|
Length | 53.000 ft |
LOA | 53.000 ft |
LWL | 47.250 ft |
Beam | 15.000 ft |
Displacement | 44000 lb |
Max Draft | 4.500 ft |
The standard boat dimensions
i | 53.58 ft |
---|---|
j | 19 ft |
p | 45.54 ft |
e | 20 ft |
p2 | - |
e2 | - |
i2 | - |
j2 | - |
I | J | P | E | P2 | E2 | I2 | J2 |
---|---|---|---|---|---|---|---|
53.58 ft | 19 ft | 45.54 ft | 20 ft | - | - | - | - |
Sails
Sail Type | MAINSAIL |
---|---|
Luff | * 45.54 ft - (13881 mm) |
Foot | * 20 ft - (6096 mm) |
Leech | * 48.8 ft - (14874 mm) |
Tack Angle | * 88 ° |
Diagonal | * 49.09 ft - (14963 mm) |
Head (inches) | * 6 in - (152 mm) |
Area | * 465.09 ft² |
Sail Type | JIBSAIL |
---|---|
Luff | * 45.48 ft - (13862 mm) |
Foot | * 25.63 ft - (7812 mm) |
Leech | * 38.82 ft - (11832 mm) |
Percentage LP | * 115 % |
Length Perpendicular | * 21.85 ft - (6660 mm) |
Deck Angle | * 11.98 ° |
Area | * 496.91 ft² |
Sail Type | GENOA |
---|---|
Luff | * 54.01 ft - (16462 mm) |
Foot | * 31.08 ft - (9473 mm) |
Leech | * 50.44 ft - (15374 mm) |
Percentage LP | * 150 % |
Length Perpendicular | * 28.5 ft - (8687 mm) |
Deck Angle | * 3.98 ° |
Area | * 769.69 ft² |
Sail Type | DRIFTER |
---|---|
Luff | * 54.01 ft - (16462 mm) |
Foot | * 32.44 ft - (9888 mm) |
Leech | * 47.91 ft - (14603 mm) |
Perc LP | * 150 % |
Length Perp | * 28.5 ft - (8687 mm) |
Deck Angle | * 9.01 ° |
Area | * 769.61 ft² |
Sail Type | ASYMMETRICAL |
---|---|
Luff | * 54.01 ft - (16462 mm) |
Foot | * 31.35 ft - (9555 mm) |
Leech | * 49.69 ft - (15146 mm) |
Perc LP | * 165 % |
Area | * 1270 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
