FOLBOT CANOE
Description
The FOLBOT CANOE is a sailboat.
Sail calculations are not available for this boat as some dimensions are missing.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 14.000 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | JIBSAIL |
|---|---|
| Luff | 12 ft - (3658 mm) |
| Foot | 6.75 ft - (2057 mm) |
| Leech | 10.92 ft - (3328 mm) |
| Length Perpendicular | 6.08 ft - (1853 mm) |
| Area | * 36.49 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | 13.5 ft - (4115 mm) |
| Foot | 7.83 ft - (2387 mm) |
| Leech-AftHdBd | * 15.19 ft - (4630 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 15.37 ft - (4685 mm) |
| Head (inches) | * 3.5 in |
| Area (no Roach) | * 54.57 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
