Evelyn 42
Description
The EVELYN 42 is a performance cruiser designed by Robert Evelyn. This substantial yacht offers spacious accommodations and excellent seakeeping, Her generous sail plan delivers excellent light-air performance. A true blue water cruiser capable of comfortable ocean passages.
Construction Details
| Designer | Robert Evelyn |
|---|---|
| Length | 42.000 ft |
| LOA | 42.170 ft |
| LWL | 37.000 ft |
| Beam | 12.500 ft |
| Displacement | 9600 lb |
| Max Draft | 7.330 ft |
The standard boat dimensions
| i | 52.37 ft |
|---|---|
| j | 16.60 ft |
| p | 45 ft |
| e | 17 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 52.37 ft | 16.60 ft | 45 ft | 17 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 45 ft - (13716 mm) |
| Foot | * 17 ft - (5182 mm) |
| Leech | * 47.37 ft - (14438 mm) |
| Tack Angle | * 88.01 ° |
| Diagonal | * 47.55 ft - (14493 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | 382.1 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 43.95 ft - (13396 mm) |
| Foot | * 21.95 ft - (6690 mm) |
| Leech | * 38.22 ft - (11649 mm) |
| Percentage LP | * 115 % |
| Length Perpendicular | * 19.09 ft - (5819 mm) |
| Deck Angle | * 12 ° |
| Area | 419.46 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 52.19 ft - (15908 mm) |
| Foot | * 26.78 ft - (8163 mm) |
| Leech | * 49.12 ft - (14972 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 24.9 ft - (7590 mm) |
| Deck Angle | * 4 ° |
| Area | 649.83 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Stays | * 52.19 ft - (15908 mm) |
| MidGirth | * 29.88 ft - (9107 mm) |
| Foot | * 29.88 ft - (9107 mm) |
| Perc LP | * 180 % |
| Area | 1325.52 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
