Elan 410
Description
The Elan 410 is a dinghy designed by Rob Humphreys. This nimble dinghy is designed for responsive sailing and easy handling, featuring variable draft for versatility in different sailing conditions. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Rob Humphreys |
|---|---|
| Length | 40.260 ft |
| LOA | 19.030 ft |
| LWL | 16.400 ft |
| Beam | 8.170 ft |
| Displacement | 1433 lb |
| Max Draft | 4.270 ft |
| Min Draft | 1.640 ft |
The standard boat dimensions
| i | 54.66 ft |
|---|---|
| j | 15.19 ft |
| p | 53.02 ft |
| e | 17.81 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 54.66 ft | 15.19 ft | 53.02 ft | 17.81 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 53.02 ft - (16160 mm) |
| Foot | * 17.81 ft - (5428 mm) |
| Leech-AftHdBd | * 55.07 ft - (16785 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 55.34 ft - (16868 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 483.48 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 45.39 ft - (13835 mm) |
| Foot | * 19.7 ft - (6005 mm) |
| Leech | * 40.27 ft - (12274 mm) |
| Percentage LP | * 115.01 % |
| Length Perpendicular | * 17.47 ft - (5325 mm) |
| Deck Angle | * 12 ° |
| Area | * 396.46 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 53.89 ft - (16426 mm) |
| Foot | * 24.17 ft - (7367 mm) |
| Leech | * 51.16 ft - (15594 mm) |
| Percentage LP | * 149.97 % |
| Length Perpendicular | * 22.78 ft - (6943 mm) |
| Deck Angle | * 4 ° |
| Area | * 613.78 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | 55 ft - (16764 mm) |
| Foot | 26.5 ft - (8077 mm) |
| Leech | 51 ft - (15545 mm) |
| Perc LP | * 165 % |
| Area | * 1093 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
