EASTERLY 30
Description
The EASTERLY 30 is a sailboat. Her generous sail plan delivers excellent light-air performance.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 30.000 ft |
The standard boat dimensions
| i | 36.16 ft |
|---|---|
| j | 10.75 ft |
| p | 31 ft |
| e | 12 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 36.16 ft | 10.75 ft | 31 ft | 12 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 31 ft - (9449 mm) |
| Foot | * 12 ft - (3658 mm) |
| Leech-AftHdBd | * 32.61 ft - (9940 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 32.85 ft - (10013 mm) |
| Head (inches) | * 5.25 in |
| Area (no Roach) | * 191.88 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | * 35.84 ft - (10924 mm) |
| Foot | * 17.21 ft - (5246 mm) |
| Leech | * 33.89 ft - (10330 mm) |
| Percentage LP | * 149.95 % |
| Length Perpendicular | * 16.12 ft - (4913 mm) |
| Deck Angle | * 3.95 ° |
| Area | * 288.86 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 30.18 ft - (9199 mm) |
| Foot | * 14.07 ft - (4289 mm) |
| Leech | * 26.51 ft - (8080 mm) |
| Percentage LP | * 114.98 % |
| Length Perpendicular | * 12.36 ft - (3767 mm) |
| Deck Angle | * 12 ° |
| Area | * 186.48 ft² |
| Sail Type | SPINNAKER |
|---|---|
| Luff | * 35.84 ft - (10924 mm) |
| MidGirth | * 19.35 ft - (5898 mm) |
| Foot | * 19.35 ft - (5898 mm) |
| Perc LP | * 180 |
| Area | * 589 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 35.84 ft - (10924 mm) |
| Foot | * 17.74 ft - (5407 mm) |
| Leech | * 32.97 ft - (10049 mm) |
| Perc LP | * 165 |
| Area | * 477 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 34.5 ft - (10516 mm) |
| Foot | 15.5 ft - (4724 mm) |
| Leech | 32.5 ft - (9906 mm) |
| Percentage LP | * 135.07 % |
| Length Perpendicular | * 14.52 ft - (4426 mm) |
| Deck Angle | * 3.93 ° |
| Area | * 250.47 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
