Dart Dinghy
Description
The DART DINGHY is a dinghy. This pocket cruiser packs surprising capability into a small package, making her ideal for exploring shallow waters and protected anchorages. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 13.000 ft |
| LOA | 16.390 ft |
| Beam | 6.070 ft |
| Displacement | 187 lb |
| Max Draft | 2.000 ft |
| Min Draft | 0.330 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | 14.50 ft |
| e | 10.37 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | 14.50 ft | 10.37 ft | - | - |
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | 14.5 ft - (4420 mm) |
| Foot | 10.38 ft - (3164 mm) |
| Leech | * 17.32 ft - (5279 mm) |
| Tack Angle | * 88.03 ° |
| Diagonal | * 17.54 ft - (5346 mm) |
| Head (inches) | * 4.5 in - (114 mm) |
| Area | 75.12 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
