Command 10 (Farrier C-10)
Description
The Command 10 (also known as Farrier Command 10 or C-10) is a high-performance folding trimaran designed by renowned multihull specialist Ian Farrier (of Farrier Marine) and introduced in the early 1980s (plans available since around 1983), with amateur plywood construction emphasized for home builders, though some professionally built examples exist. Production was primarily owner-built or small-scale (exact quantities unknown but limited compared to production monohulls), with boats still appearing on the used market today. It stands out for its patented Farrier folding amas (beams fold inward for trailering and marina berthing, reducing beam from ~27 ft / 8.2 m to trailerable width), exceptional speed and stability as an ocean-capable cruiser (designed for offshore passages with robustness beyond 20 knots), comfortable accommodations (sleeps 4–5 with enclosed head and galley), lightweight yet strong plywood/epoxy build, centerboard for shallow draft when raised, and fast, exciting sailing performance while remaining fully trailerable.
Construction Details
| Designer | Ian Farrier |
|---|---|
| Builder | Farrier Marine |
| Length | 32.750 ft |
| LOA | 32.810 ft |
| LWL | 30.150 ft |
| Beam | 26.740 ft |
| Displacement | 5512 lb |
| Max Draft | 5.740 ft |
| Min Draft | 2.260 ft |
| Year Built | 1983 |
The standard boat dimensions
| i | 38.50 ft |
|---|---|
| j | 12.17 ft |
| p | 41 ft |
| e | 13.42 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 38.50 ft | 12.17 ft | 41 ft | 13.42 ft | - | - | - | - |
Sails
Command 10 (Farrier C-10) - MAINSAIL
| Luff | 40 ft - (12192 mm) |
|---|---|
| Foot | 13.46 ft - (4103 mm) |
| Leech | * 41.48 ft - (12643 mm) |
| Tack Angle | * 87.97 ° |
| Diagonal | 41.75 ft - (12725 mm) |
| Head (inches) | * 6 in - (152 mm) |
| Area | * 277.79 ft² |
| Edit in Calculator |
Command 10 (Farrier C-10) - JIBSAIL
| Luff | 28 ft - (8534 mm) |
|---|---|
| Foot | 10.83 ft - (3301 mm) |
| Leech | 22.92 ft - (6986 mm) |
| Percentage LP | * 69.84 % |
| Length Perpendicular | * 8.5 ft - (2591 mm) |
| Deck Angle | * 20.77 ° |
| Area | * 118.97 ft² |
| Edit in Calculator |
Command 10 (Farrier C-10) - JIBSAIL
| Luff | 38.5 ft - (11735 mm) |
|---|---|
| Foot | 11.83 ft - (3606 mm) |
| Leech | 34.92 ft - (10644 mm) |
| Percentage LP | * 87.18 % |
| Length Perpendicular | * 10.61 ft - (3234 mm) |
| Deck Angle | * 8.7 ° |
| Area | * 204.25 ft² |
| Edit in Calculator |
Command 10 (Farrier C-10) - GENOA
| Luff | 38.5 ft - (11735 mm) |
|---|---|
| Foot | 17.17 ft - (5233 mm) |
| Leech | 34.58 ft - (10540 mm) |
| Percentage LP | * 126.71 % |
| Length Perpendicular | * 15.42 ft - (4700 mm) |
| Deck Angle | * 8.54 ° |
| Area | * 296.86 ft² |
| Edit in Calculator |
Command 10 (Farrier C-10) - GENOA
| Luff | 44.92 ft - (13692 mm) |
|---|---|
| Foot | 19.83 ft - (6044 mm) |
| Leech | 41 ft - (12497 mm) |
| Percentage LP | * 148.64 % |
| Length Perpendicular | * 18.09 ft - (5514 mm) |
| Deck Angle | * 6.65 ° |
| Area | * 406.27 ft² |
| Edit in Calculator |
Command 10 (Farrier C-10) - SPINNAKER
| Stays | 41.83 ft - (12750 mm) |
|---|---|
| MidGirth | 19.83 ft - (6044 mm) |
| Foot | 19.83 ft - (6044 mm) |
| Perc LP | * 180 % |
| Area | * 705 ft² |
| Edit in Calculator |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
