Cascade
Description
18000 disp. Sloop rig with staysail.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 42.000 ft |
The standard boat dimensions
| i | 48.38 ft |
|---|---|
| j | 14.46 ft |
| p | 43.25 ft |
| e | 19.38 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 48.38 ft | 14.46 ft | 43.25 ft | 19.38 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | GENOA |
|---|---|
| Luff | * 47.97 ft - (14621 mm) |
| Foot | * 23.18 ft - (7065 mm) |
| Leech | * 45.32 ft - (13814 mm) |
| Percentage LP | * 150 % |
| Length Perpendicular | * 21.69 ft - (6611 mm) |
| Deck Angle | * 4.02 ° |
| Area | * 520.23 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | * 40.4 ft - (12314 mm) |
| Foot | * 18.95 ft - (5776 mm) |
| Leech | * 35.46 ft - (10808 mm) |
| Percentage LP | * 115.01 % |
| Length Perpendicular | * 16.63 ft - (5069 mm) |
| Deck Angle | * 12 ° |
| Area | * 335.96 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 43.25 ft - (13183 mm) |
| Foot | * 9.38 ft - (2859 mm) |
| Leech-AftHdBd | * 43.73 ft - (13329 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 43.93 ft - (13390 mm) |
| Head (inches) | * 4.5 in |
| Area (no Roach) | * 209.67 ft² |
| Sail Type | ASYMMETRICAL |
|---|---|
| Luff | * 47.97 ft - (14621 mm) |
| Foot | * 23.86 ft - (7273 mm) |
| Leech | * 44.13 ft - (13451 mm) |
| Perc LP | * 165 |
| Area | * 858 ft² |
| Sail Type | STORMJIB |
|---|---|
| Luff | * 27.77 ft - (8464 mm) |
| Foot | * 10.68 ft - (3255 mm) |
| Leech | * 23.23 ft - (7081 mm) |
| Perc LP | * 60.03 |
| Length Perp | * 8.68 |
| Deck Angle | * 19 ° |
| Area | * 120.52 ft² |
| Sail Type | MAINSAIL |
|---|---|
| Luff | * 43.25 ft - (13183 mm) |
| Foot | * 19.38 ft - (5907 mm) |
| Leech-AftHdBd | * 46.48 ft - (14167 mm) |
| Tack Ang | * 88 ° |
| Diag (clew/head) | * 46.77 ft - (14255 mm) |
| Head (inches) | * 6 in |
| Area (no Roach) | * 428.34 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
