Caliber 33
Description
The Caliber 33 is a classic American bluewater cruising cutter designed by Michael McCreary. Built by Caliber Yachts in Clearwater, Florida, from 1986 to 1991, approximately 70 hulls were produced. It features a moderate-displacement fin keel with skeg-hung rudder for protected tracking and stability, solid hand-laid fiberglass construction (balsa-cored deck for strength), and a cutter rig for versatile sail handling on coastal or short offshore passages. Renowned for its seaworthiness, dry center cockpit, and balanced performance in 10–20 knots, it's well-suited for couples or small families, with a stiff, forgiving ride; however, as 35+ year-old boats, surveys should prioritize chainplates, keel bolts, and thru-hull fittings. Note: This model was later extended (transom) and renamed the Caliber 35 in 1992, evolving further into the Caliber 35 LRC in 1995.
Construction Details
| Designer | Michael McCreary |
|---|---|
| Builder | Caliber Yachts |
| Length | 32.500 ft |
| LOA | 32.500 ft |
| LWL | 29.500 ft |
| Beam | 11.330 ft |
| Displacement | 13000 lb |
| Ballast | 6100 lb |
| Max Draft | 4.500 ft |
| Year Built | 1984 |
The standard boat dimensions
| i | 43 ft |
|---|---|
| j | 14 ft |
| p | 39.10 ft |
| e | 12 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| 43 ft | 14 ft | 39.10 ft | 12 ft | - | - | - | - |
Sails
Caliber 33 - MAINSAIL
| Luff | 39.1 ft - (11918 mm) |
|---|---|
| Foot | 12 ft - (3658 mm) |
| Leech | * 40.26 ft - (12271 mm) |
| Tack Angle | * 88 ° |
| Diagonal | * 40.5 ft - (12344 mm) |
| Head (inches) | * 5.25 in - (133 mm) |
| Area | * 241.85 ft² |
| Edit in Calculator | |
Caliber 33 - JIBSAIL
| Luff | 36.18 ft - (11028 mm) |
|---|---|
| Foot | * 18.59 ft - (5666 mm) |
| Leech | 31.33 ft - (9549 mm) |
| Percentage LP | 115 % |
| Length Perpendicular | * 16.1 ft - (4907 mm) |
| Area | * 291.18 ft² |
| Edit in Calculator | |
Caliber 33 - GENOA
| Luff | 42.96 ft - (13094 mm) |
|---|---|
| Foot | * 22.65 ft - (6904 mm) |
| Leech | 40.36 ft - (12302 mm) |
| Percentage LP | 150 % |
| Length Perpendicular | * 21 ft - (6401 mm) |
| Area | * 451.03 ft² |
| Edit in Calculator | |
Caliber 33 - DRIFTER
| Luff | 43 ft - (13106 mm) |
|---|---|
| Foot | 24 ft - (7315 mm) |
| Leech | 38.5 ft - (11735 mm) |
| Perc LP | * 152.5 % |
| Length Perp | * 21.35 ft - (6507 mm) |
| Deck Angle | * 9.14 ° |
| Area | * 459.03 ft² |
| Edit in Calculator | |
Caliber 33 - ASYMMETRICAL
| Luff | 43 ft - (13106 mm) |
|---|---|
| Foot | 23.25 ft - (7087 mm) |
| Leech | 39.5 ft - (12040 mm) |
| Perc LP | 165 % |
| Area | * 750 ft² |
| Edit in Calculator | |
Caliber 33 - SPINNAKER
| Stays | 42.96 ft - (13094 mm) |
|---|---|
| MidGirth | 25.2 ft - (7681 mm) |
| Foot | 25.2 ft - (7681 mm) |
| Perc LP | * 180 % |
| Area | * 920 ft² |
| Edit in Calculator | |
Caliber 33 - STORMJIB
| Luff | 23 ft - (7010 mm) |
|---|---|
| Foot | 10 ft - (3048 mm) |
| Leech | 19 ft - (5791 mm) |
| Perc LP | * 58.07 % |
| Length Perp | * 8.13 ft - (2478 mm) |
| Deck Angle | * 17.6 ° |
| Area | * 93.47 ft² |
| Edit in Calculator | |
Caliber 33 - STORMTRYSAIL
| Luff | 19.5 ft - (5944 mm) |
|---|---|
| Foot | 10.5 ft - (3200 mm) |
| Leech | 25 ft - (7620 mm) |
| Length Perp | * 11.68 ft - (3560 mm) |
| Tack Angle | * 12.57 ° |
| Area | * 97 ft² |
| Edit in Calculator | |
