Buzzards Bay 19
Description
The Buzzards Bay 19 is a dinghy. This pocket cruiser packs surprising capability into a small package, featuring variable draft for versatility in different sailing conditions. Perfect for day sailing, club racing, or teaching young sailors the ropes.
Custom sail calculations are not possible for this boat as no I, J, P and E dimensions are available.
Construction Details
| Designer | Unknown |
|---|---|
| Length | 19.000 ft |
| LOA | 17.250 ft |
| LWL | 14.000 ft |
| Beam | 5.830 ft |
| Displacement | 1700 lb |
| Max Draft | 2.500 ft |
| Min Draft | 2.330 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | - |
| e | - |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| - | - | - | - | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, E, and P)
| Sail Type | JIBSAIL |
|---|---|
| Luff | 15 ft - (4572 mm) |
| Foot | 7.75 ft - (2362 mm) |
| Leech | 13.25 ft - (4039 mm) |
| Area | * 51.27 ft² |
| Sail Type | GAFF MAIN |
|---|---|
| Luff | 14 ft - (4267 mm) |
| Foot | 13 ft - (3962 mm) |
| Leech | 18.75 ft - (5715 mm) |
| Tack Angle | * 79.32 ° |
| Diag (clew/throat) | 17.25 ft - (5258 mm) |
| Head | 6 ft - (1829 mm) |
| Area | * 140.97 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite.
