Brown Banca Cat
Description
The BROWN BANCA CAT is a sailboat designed by Jim Brown.
The standard boat dimensions
| i | 28.33 ft |
|---|---|
| j | 10 ft |
| p | 32.33 ft |
| e | 15.75 ft |
| p2 | - |
| e2 | - |
| I | J | P | E | P2 | E2 |
|---|---|---|---|---|---|
| 28.33 ft | 10 ft | 32.33 ft | 15.75 ft | - | - |
Sails
An asterisk indicates that a computer algorithm was used to determine the dimension based on sailboat rig dimensions (usually the I, J, P, and E)
| Sail Type | MAINSAIL |
|---|---|
| Luff | 32.33 ft - (9854 mm) |
| Foot | 15.75 ft - (4801 mm) |
| Leech | 35.37 ft - (10781 mm) |
| Tack Angle | * 88.14 ° |
| Diagonal | 35.5 ft - (10820 mm) |
| Head (inches) | 6 in - (152 mm) |
| Area | * 263.01 ft² |
| Sail Type | JIBSAIL |
|---|---|
| Luff | 22 ft - (6706 mm) |
| Foot | 13.33 ft - (4063 mm) |
| Leech | 16.5 ft - (5029 mm) |
| Percentage LP | * 99.7 % |
| Length Perpendicular | * 9.97 ft - (3039 mm) |
| Deck Angle | * 22.16 ° |
| Area | * 109.64 ft² |
| Sail Type | GENOA |
|---|---|
| Luff | 27 ft - (8230 mm) |
| Foot | 18.167 ft - (5537 mm) |
| Leech | 26 ft - (7925 mm) |
| Percentage LP | * 167.2 % |
| Length Perpendicular | * 16.72 ft - (5096 mm) |
| Deck Angle | * 3.54 ° |
| Area | * 225.79 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
