Banshee
Description
The Banshee (also known as the Banshee 13) is an American high-performance one-design sailing dinghy designed by Richard L. Reid and first built in 1969 by Marine Plastics in Foster City, California. As demand grew, production was subcontracted to various yards, and in 1972, Barry Bruch formed Banshee International, Inc., which took over manufacturing until the mid-1980s. Abbott Boats in Sarnia, Ontario, Canada, was licensed to build up to 500 units, though the exact total production is unknown (estimates suggest several hundred worldwide). It's celebrated as a fast, responsive daysailer and racer, predating the Laser by a year and competing directly with it in the 13-foot class. The lightweight fiberglass construction, cat rig, and daggerboard make it ideal for single-handed or short-handed (1–2 people) racing in protected waters like bays or lakes, with a Portsmouth Yardstick rating of 93.7 (indicating speed comparable to a Laser at 91.3).
Construction Details
| Designer | Richard L. Reid |
|---|---|
| Builder | Marine Plastics |
| Length | 13.000 ft |
| LOA | 13.000 ft |
| LWL | 12.000 ft |
| Beam | 4.920 ft |
| Displacement | 115 lb |
| Max Draft | 2.750 ft |
| Min Draft | 0.330 ft |
The standard boat dimensions
| i | - |
|---|---|
| j | - |
| p | 18.42 ft |
| e | 8.40 ft |
| p2 | - |
| e2 | - |
| i2 | - |
| j2 | - |
| I | J | P | E | P2 | E2 | I2 | J2 |
|---|---|---|---|---|---|---|---|
| - | - | 18.42 ft | 8.40 ft | - | - | - | - |
Documents
Sails
| Sail Type | MAINSAIL |
|---|---|
| Luff | 18.5 ft - (5639 mm) |
| Foot | 8.313 ft - (2534 mm) |
| Leech | 18.98 ft - (5785 mm) |
| Tack Angle | * 80.58 ° |
| Diagonal | 19 ft - (5791 mm) |
| Head (inches) | 0.5 in - (13 mm) |
| Area | * 76.21 ft² |
Disclaimer. Boats are not all the same -- even when produced in the same factory of the same model. Sailrite does its best to publish accurate dimensions, but we often find it worthwhile to have our customers measure their boats carefully before we produce kits for them. You should take the same precautions, especially when the data is not from Sailrite. The information on this site is not guaranteed to be accurate. Sailrite offers this content as a service to our community, but takes no responsibility for the reliability of the data provided.
